1 FEATURES AND TECHNICAL DATA
1.1 FEATURES
1.1.1 Operation
The TS 2000 gas-red convector is an independent heat-
ing appliance with sealed combustion chamber and natu-
ral draught with balanced ow.
It has been designed to be installed inside the room to be
heated.
It can operate either with natural gas (G20) and LPG (G30/
G31) (gas-red convector belonging to category II
2H3+
ac-
cording to EN 613).
The combustion air intake and the ue gas outlet take
place outside the installation room by means of two coax-
ial pipes. Therefore the appliance must be positioned on
an external perimeter wall.
The dual function of air intake and ue gas exhaust per-
formed by the coaxial duct does not allow for connection
to traditional ues.
The operation principle of the TS 2000 gas-red convec-
tor is based on a convective motion of room air that pass-
es through the gas-red convector from bottom to top,
is heated and diused into the room through the upper
grille.
For this reason it is important not to obstruct
the air outlet by placingclothing or any other
objects over the outlet grille; always keep cur-
tains, chairs or any other furniture at least 30
cm away from the heater.
The operation of the appliance, which is very simple in
itself, is made completely automatic by the thermostatic
regulation: in fact, the user only requires the preliminary
ignition operation and the choice of the desired tempera-
ture (set on the thermostatic control knob).
The sealed combustion chamber is the best guarantee of
safety for the environment in which the gas-red convec-
tor is installed: there is no possibility of the products of
combustion leak, nor is the oxygen necessary for combus-
tion taken from the environment. The appliance, once in-
stalled in accordance with the installation standards, does
not require any ventilation openings in the room.
A ame detection device using a thermocouple interrupts
the gas supply in the event of an accidental shutdown.
1.1.2 Mechanical components
▶ Sealed combustion chamber.
▶ High-eciency aluminium alloy heat exchanger.
▶ Ø 100/60 mm coaxial combustion air intake and ue
gas exhaust pipes.
▶ External ue gas terminal in aluminium alloy.
▶ Casing in epoxy powder-coated sheet metal.
▶ Support bracket for wall mounting.
1.1.3 Control and safety devices
▶ Gas valve providing the following functions:
 burner ignition
 ame monitoring
 heat exchanger temperature probe control
▶ Heat exchanger temperature control probe
▶ Piezoelectric ignition button
▶ Thermostatic control knob
1.2 DIMENSIONS
Figure1.1 Dimensions
170
100
480
190 290
100
100
< 350
> 50
100
100
577
