Electrical diagram RE DOPPIA CE / single phase
POS
DESCRIPTION
1
Power cord
2
Terminal board
3
On-Off switch
4
Control lamp
5
Control board
6
Pump
7
Solenoid valve group 1
8
Solenoid valve group 2
9
Solenoid valve group 3
10
Solenoid valve group 4
11
Solenoid valve boiler fill
12
Solenoid valve hot water
13
Solenoid valve hot water tempering valve
14
Touchpad group 1
15
Touchpad group 2
16
Touchpad group 3
17
Touchpad group 4
18
SSR second boiler 4 group machine
19
Heating element second boiler 4 group machine
20
Bipolar safety thermostat second boiler 4 group machine
21
NTC probe boiler 2 and 3 group machine
22
Display LCD
23
Boiler level control
24
Boiler pressure transducer
25
Flowmeter group 1
26
Flowmeter group 2
