Rocket RE DOPPIA Series User Manual

_____________________________________________________________________________________________
© Rocket Milano s.r.l. - RE DOPPIA series. User Manual Ed. 01.2019. Specifications subject to change without notice. Page 29
HYDRAULIC DIAGRAM
POS
DESCRIPTION
1
Water inlet filter
2
Pump
3
Manual boiler fill
4
Non return valve
5
Solenoid valve service boiler fill
6
Solenoid valve hot water tempering
7
Flowmeter
8
Service boiler
9
Vacuum breaker valve
10
Boiler safety valve
11
Solenoid valve vacuum breaker
12
Hot water solenoid valve
13
Steam valve
14
Hot water wand
15
Steam wand
16
Coffee boiler
17
Brewing head (“group”)
18
Solenoid valve brewing head
19
Drain valve
20
Service boiler pressure gauge
21
Pump pressure gauge
22
Drain reservoir
23
Expansion valve
