RF-TVMFM03 TV Wall Mount
Step 8 Attach your TV to the wall mount
1 Slide the top and bottom edges of the arm assembly under the metal tabs on the TV horizontal brackets (C).
2 Align the center hole in the lower horizontal bar (C) with the hole in the face of the arm assembly (D) and
secure your TV with the bracket screw (X).
You’ll need
HEAVY! You will need
assistance with this step.
X (1) Phillips screwdriver
