9RF-RBWS01
4
Sender mode indicator Turns blue when sending audio.
Note: This indicator will light automatically when a 3.5 mm connector or USB cable is attached
to the device (the device senses the cable connection).
5
Source Press to select different audio streams on your Rocketboost network. Each press moves to the
next source.
6
Receiver mode
indicator
Turns blue when receiving audio from a Rocketboost wireless sender. Blinks slowly if the current
source listened to is muted.
Note: This indicator will not be lit if the Rocketboost wireless sender is turned off. Press the
SOURCE button to find the next available source.
7
Line in indicator Turns blue when an audio source device is plugged into the Line In jack.
Note: The indicator does not light when a USB cable is connected to the USB jack.
8
Remote control sensor
window
Receives the signal from the remote control.
# Feature Description
