29
Publication 1763-IN001C-EN-P - June 2015
Relay Outputs
Turn On Time/Turn Off Time
10 msec (maximum)
(2)
Relay life - Electrical (Resistive Load) Refer to Relay Life Chart
Relay life - Mechanical 10,000,000 cycles
Load Current 10 mA (minimum)
(1)
3.0 A above 40 °C.
(2)
Scan time dependent.
Relay Contact Ratings
(1)
(1)
Pilot Duty Rating: (ordinary location) – B300, R150. (hazardous location) – C300, R150.
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
240V AC
(2)
(2)
For AC voltage applications lower than 240V AC but higher than 120V AC, the maximum make and break ratings are to be
obtained by dividing the volt-amperes rating by the application voltage.
15.0 A 1.5 A
5.0 A
(5)
(5)
3.0 A above 40 °C.
3600 VA 360 VA
120V AC
(3)
(3)
For AC voltage applications lower than 120V AC, the maximum make current is to be the same as for 120V AC, and the
maximum break current is to be obtained by dividing the break volt-amperes rating by the application voltage, but the
currents are not to exceed the thermal continuous current.
30.0 A 3.0 A 3600 VA 360 VA
125V DC
(4)
(4)
For DC voltage applications lower than 125V DC, the make/break ampere rating for relay contacts can be determined by
dividing the volt-ampere rating by the applied DC voltage but the current values are not to exceed the thermal continuous
current.
0.22 A 1.0 A 28 VA
Do not exceed the “Current per group common” specification.
General
Description 1763
-L16AWA, -L16BWA,
-L16DWD
-L16BBB
