Rockwell Automation 2711P-RPA User Manual

8 Logic Module, Internal CompactFlash, and RAM
Publication 2711P-IN004J-EN-P - September 2009
Install or Replace the Internal CompactFlash
The logic module is available with or without CompactFlash installed. If ordered separately,
you must install the CompactFlash before attaching the logic module to the display module.
Internal CompactFlash
Follow these steps to replace the internal CompactFlash.
1. Turn the logic module over to expose the circuit board.
2. Unscrew and remove the retaining clip that secures the internal CompactFlash card.
3. Pull out the internal CompactFlash card.
4. Insert the new internal CompactFlash card.
5. Reattach the retaining clip.
Cat. No.
(1)
(1)
The 2711P-RP, 2711P-RPD, and 2711P-RPA logic modules are compatible with any of the internal CompactFlash options.
Description
2711P-RW1 64 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus
logic modules
2711P-RW2 128 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus
logic modules
2711P-RW3 256 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus
logic modules
2711P-RW6 128 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus CE
logic modules
2711P-RW7 256 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus CE logic
modules
2711P-RW8 512 MB internal CompactFlash with FactoryTalk View ME software for PanelView Plus CE logic
modules
