1719 Ex I/O Installation Instructions
Prevent Electrostatic Discharge
North American Hazardous Location Approval
European Hazardous Location Approval
ATTENTION: This equipment is sensitive to electrostatic discharge, which can cause internal damage and affect normal operation. Follow these
guidelines when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• Use a static-safe workstation, if available.
• Store the equipment in appropriate static-safe packaging when not in use.
The Following Information Applies When Operating This Equipment In
Hazardous Locations.
Informations sur l’utilisation de cet équipement en environnements dangereux.
Products marked “CL I, DIV 2, GP A, B, C, D” are suitable for use in Class I Division 2
Groups A, B, C, D, Hazardous Locations and nonhazardous locations only. Each
product is supplied with markings on the rating nameplate indicating the hazardous
location temperature code. When combining products within a system, the most
adverse temperature code (lowest “T” number) may be used to help determine the
overall temperature code of the system. Combinations of equipment in your system
are subject to investigation by the local Authority Having Jurisdiction at the time
of installation.
Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne conviennent qu'à une utilisation en
environnements de Classe I Division 2 Groupes A, B, C, D dangereux et non
dangereux. Chaque produit est livré avec des marquages sur sa plaque
d'identification qui indiquent le code de température pour les environnements
dangereux. Lorsque plusieurs produits sont combinés dans un système, le code de
température le plus défavorable (code de température le plus faible) peut être utilisé
pour déterminer le code de température global du système. Les combinaisons
d'équipements dans le système sont sujettes à inspection par les autorités locales
qualifiées au moment de l'installation.
WARNING:
Explosion Hazard –
• Do not disconnect equipment unless power has been removed or
the area is known to be nonhazardous.
• Do not disconnect connections to this equipment unless power has
been removed or the area is known to be nonhazardous. Secure any
external connections that mate to this equipment by using screws,
sliding latches, threaded connectors, or other means provided with
this product.
• Substitution of components may impair suitability for Class I,
Division 2.
AVERTISSEMENT:
Risque d’Explosion –
• Couper le courant ou s'assurer que l'environnement est classé non
dangereux avant de débrancher l'équipement.
• Couper le courant ou s'assurer que l'environnement est classé non
dangereux avant de débrancher les connecteurs. Fixer tous les
connecteurs externes reliés à cet équipement à l'aide de vis,
loquets coulissants, connecteurs filetés ou autres moyens fournis
avec ce produit.
• La substitution de composants peut rendre cet équipement
inadapté à une utilisation en environnement de Classe I, Division 2.
The following applies to products marked
II 3 G. Such modules:
• Are Equipment Group II, Equipment Category 3, and comply with the Essential Health and Safety Requirements relating to the design and construction of such
equipment given in Annex II to Directive 2014/34/EU. For details, see the EU Declaration of Conformity from the 1719 Certification Bulletin, publication 1719-CT001.
• Are intended for use in areas in which explosive atmospheres caused by gases, vapors, mists, or air are unlikely to occur, or are likely to occur only infrequently and
for short periods. Such locations correspond to Zone 2 classification according to ATEX directive 1999/92/EC.
• The I/O modules are associated apparatus with outputs leading into Category 1
[Zone 0 (gas) or Zone 20 (dust)].
1719-CF4H
• Field connections and mounting: the type of protection is “Ex nA [ia Ga] IIC T4 Gc” and “[Ex ia Da] IIIC”, comply to Standards EN 60079-0:2009, EN 60079-11:2007,
EN 60079-15:2010, and EN 60079-26:2007. Certificate BVS 11 ATEX E 116 X.
1719- IF4HB
• Field connections and mounting: The type of protection is “Ex nA [ia Ga] IIC T4 Gc” and “[Ex ia Da] IIIC”, comply to Standards EN 60079-0:2009, EN 60079-11:2012,
EN 60079-15:2010, and EN 60079-26:2007. Certificate BVS 12 ATEX E 024 X.
1719-IR4B, 1719-IT4B, 1719-IBN8B, 1719-IJ
• Field connections: the type of protection is “[Ex ia] IIC” and “[Ex ia] IIIC”, comply to Standards EN 60079-0:2009 and EN 60079-11:2007. Certificate PTB 03 ATEX 2042.
• Mounting: the type of protection is “Ex nA IIC T4 Gc“, comply to Standards EN 60079-0:2009 and EN 60079-15:2010. Certificate PF 08 CERT 1234 X.
1719-IBN8
• Field connections and mounting: The type of protection is “Ex nA [ia Ga] IIC T4 Gc” and “[Ex ia Da] IIIC”, comply to Standards EN 60079-0:2012/A11:2013, EN 60079-
11:2012 and EN 60079-15:2010. Certificate EXA 13 ATEX 0036X.
1719-OB2, 1719-OB2L
• Field connections and mounting: The type of protection is “Ex nA [ia Ga] IIC T4 Gc”, and “[Ex ia Da] IIIC”, comply to Standards EN 60079-0:2012+A11:2013, EN 60079-
11:2012, and EN 60079-15:2010. Certificate EXA 16 ATEX 0025X.
1719-AENTR
• Mounting: the type of protection is “Ex nA IIC T4 Gc”, comply to Standards EN 60079-0:2012+A11:2013 and EN 60079-15:2010. Certificate DEMKO 16 ATEX 1780X.
1719-PSDC
• Mounting: the type of protection is “Ex nA IIC T4 Gc”, comply to Standards EN 60079-0:2009 and EN 60079-15:2010. Certificate PF 08 CERT 1234 X.
