Appendix F MicroLogix 1400 Distributed Network Protocol
1RESTART
0 when the controller is or was in Non-executing mode.
0 when the controller is or was in Executing mode and the configuration file does not exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
2 COMM_LOST
3 REMOTE_FORCED
4 LOCAL_FORCED
5 ROLLOVER
6 DISCONTINUITY
7reserved
Object Flags for Counter (Continued)
Bit Offset Name Description
Object Flags for Analog Input
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode and the configuration file does not exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
1RESTART
0 when the controller is or was in Non-executing mode.
0 when the controller is or was in Executing mode and the configuration file does not exist.
May be 1 when the controller is in Executing mode and the configuration file exists.
2 COMM_LOST
3 REMOTE_FORCED
4 LOCAL_FORCED
5 OVER_RANGE
6 REFERENCE_ERR
7reserved
Object Flags for Analog Output
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode.
1 RESTART Always 0. Not used.
2 COMM_LOST Always 0. Not used.
3 REMOTE_FORCED Always 0. Not used.
4 LOCAL_FORCED Always 0. Not used.
5 reserved Always 0. Not used.
6 reserved Always 0. Not used.
7 reserved Always 0. Not used.
Object Flags for Analog Output for Series A controllers
Bit Offset Name Description
0ONLINE
0 when the controller is or was in Non-executing mode.
1 when the controller is or was in Executing mode.
1 RESTART Always 0. Not used.
2 COMM_LOST Always 0. Not used.
3 REMOTE_FORCED Always 0. Not used.
4 LOCAL_FORCED Always 0. Not used.
5 reserved Always 0. Not used.
6 reserved Always 0. Not used.
7 reserved Always 0. Not used.
