26 Rockwell Automation Publication 20P-TD001K-EN-P - January 2021
PowerFlex DC Drive and Field Controller Technical Data
PowerFlex DC Drive Power Wiring with DC Output Contactor
C
D
PowerFlex DC
Drive
36
(9)
34
(4)
(on I/O TB4)
19
(5)
(+24V on I/O TB2)
Control
Board P/S
V2 U2
F2
35
(9)
U V W
U1 V1
C1 D1
F1
FS1
(3)
FS1
(3)
FS1
(3)
FU1 FV1
Field Power Terminal Block
Control Power / Relay Outputs Terminal Block
A1
A2
Armature Volt. Fdbk. Term. Blk.
1A1
1A2
SB
(1)
SA
(1)
M
Aux
(N.O. Relay) M1 DC Contactor
A1 A2
13 14
L1 L2 A1
T1 T2 A2
FS2
(6)
FS2
(6)
PE
AC Input Voltage
460 VAC
Max. or
230 VAC
Min.
(11)
115V or 230V AC Input Source
(1, 12)
3 Phase AC line
L1 L2 L3
Line Reactor
(2)
Isolation
Transformer
(2)
Lockable
Installation
Disconnect
Safety Ground
EMC Filter
(if used)
K1
(14)
K1
(14)
K1
(14)
Fan Power Terminal Block - Series B and C, Frame D Drives Only
(10)
400...460V AC Input Source
(12)
See footnote
(13)
FU FU FU
U3 V3 W3
Fan Power Terminal Block - Frame C and Series A, Frame D Drives Only
(10)
230V AC Input Source
(12)
See footnote
(13)
FU FU
U3 V3
For footnotes, see PowerFlex DC Drive Power Wiring Diagram Footnotes on page 28.
