Approximate Dimensions – PowerFlex DC Drives (continued)
Frame B Dimensions
Frame B Weights
mm (in.)
AA1A2A3BB1C1
C2
(1)
(1) Only frame B drive catalog numbers 20P21AD330, 20P21AD412, 20P21AE405, 20P41AB360, 20P41AB434, 20P41AD330, 20P41AD412, and 20P41AE405.
311 (12.2) 275 (10.8) 16.5 (0.65) 7 (0.3) 388 (15.3) 375 (14.8) 350 (13.8) 380 (15.0)
Drive w/ND Rating Code Weight, kg (lb)
230V 460V 575V Drive Drive and Packaging
146 167 067
25.5 (56.2) 27.5 (60.6)180 207 101
218 — 135
265 250 270 29.5 (65.0) 31.5 (69.5)
360 330 405
32 (70.5) 34 (75)
434 412 —
A
A1
B1
C
B
A2
A3
45.2 (1.8)
98.5 (3.9)
53.1 (2.1)
53.1 (2.1)
48.5 (1.9)
48.5 (1.9)
147.0 (5.8)
200.1 (7.9)
248.6 (9.8)
Terminal Details Dimensions in mm (in.)
