Preface
Overview
The purpose of this manual is to provide detailed information about configuring
PowerFlex® 750-Series products with TotalFORCE® control for common
applications.
Who Should Use This
Manual
This manual is intended for qualified personnel. You must be able to program
and operate Adjustable Frequency AC Drive devices. In addition, you must have
an understanding of the parameter settings and functions.
Manual Conventions
In this manual we refer to the PowerFlex 750-Series products with TotalFORCE
control as:
• PowerFlex 755T products when referring to the group of drives, bus
supplies, and common bus inverters.
• PowerFlex 755TL drive when referring to the low harmonic drive product.
• PowerFlex 755TR drive when referring to the regenerative drive product.
• PowerFlex 755TM drive system when referring to regenerative bus supply
and common bus inverter products.
Additional Resources
The following table lists publications that provide general drive-related
information.
Resource Description
PowerFlex 750-Series Products with TotalFORCE Control
Technical Data, publication 750-TD100
Provides detailed information about:
• Drive and bus supply specifications
• Option specifications
• Fuse and circuit breaker ratings
PowerFlex 755TM IP00 Open Type Kits Technical Data,
publication 750-TD101
Provides detailed information about:
• Kit selection
• Kit ratings and specifications
• Option specifications
PowerFlex 755TM IP00 Open Type Kits Installation
Instructions, publication 750-IN101
Provides instructions to install IP00 Open Type kits in
user-supplied enclosures.
PowerFlex 750-Series I/O, Feedback, and Power Option
Modules Installation, publication 750-IN111
Provides instructions to install and wire 750-Series
option modules.
PowerFlex Drives with TotalFORCE Control Programming
Manual, publication 750-PM100
Provides detailed information about:
• I/O, control, and feedback options
• Parameters and programming
• Faults, alarms, and troubleshooting
Drives in Common Bus Configurations with PowerFlex
755TM Bus Supplies Application Techniques, publication
DRIVES-AT005
Provides basic information to wire and ground the
following products in common bus applications:
• PowerFlex 755TM drive system for common bus
solutions
• PowerFlex 750-Series AC and DC input drive
• Kinetix® 5700 servo drives
