PowerFlex Compact-class AC Drive Setup
This chapter provides instructions on how to configure your PowerFlex AC drive to communicate with a Micro800 PLC
by using the Modbus RTU protocol. Later in this guide, the PLC is programmed to use the sample building-block code
that is supplied in this Connected Components Accelerator Toolkit (CCAT). Micro850 controllers and PowerFlex 523
drives are referenced throughout this Quick Start. Wherever a Micro850 controller is referenced, a Micro830 or Micro820
controller can also be used. Wherever a PowerFlex 523 drive is referenced, a PowerFlex 525, 4, 4M, 40, 40P, or 400 drive
can also be used.
Before You Begin
• Review the Getting Started CCAT with System Design Assistant Quick Start, publication CC-QS035.
•Apply power to your drive.
What You Need
• Personal computer with an available USB port
• Connected Components Workbench software, version 6.00 or later
• 1203-USB converter with 22-HIM-H10 cable
• PowerFlex 523, 525, 4, 4M, 40, 40P, or 400 drive
