Rockwell Automation Publication CC-QS034C-EN-P - March 2015 27
Chapter 2
System Validation
This chapter provides instructions on how to configure, connect, and validate communication between the devices in your
PowerFlex Compact-class AC drive device building-block system.
Before You Begin
• Complete the steps in Chapter 1.
• Verify that the devices are connected as shown in the assembled wiring diagrams.
• Verify that your Micro800 controller, the PowerFlex AC drive, and the PanelView 800 terminal have power applied
to them.
What You Need
• Micro820, Micro830, or Micro850 controller with Isolated Serial Port plug-in module (catalog number
2080-SERIALISOL)
• PowerFlex 523, 525, 4, 4M, 40, 40P, or 400 drive
• 4 in. (or larger) PanelView 800 terminal
• 1761-CBL-PM02, 9-pin to 8-pin MINI-DIN RS-232 communication cable, if a CIP serial connection for the
PanelView 800 terminal is used
• Two 1585J-M8xxxx-2 RJ45 Ethernet patch cords, if a CIP on Ethernet connection for the PanelView 800 terminal
is used
• 1783- USxxx Stratix 2000™ unmanaged Ethernet switch
• Two-wire, twisted-pair shielded RS-485 communication cable (Belden 3105A recommended)
• AK-U0-RJ45-TB2P, RJ45 two position terminal block with a 120 Ω terminating resistor
• USB programming cable (A to B) or Ethernet cable for personal computer to Micro800 controller communication
• Personal computer with available USB port and Ethernet connection with Connected Components Workbench
software, version 6.00 or later, installed
