RODE Microphones M2 - Microphone Specifications; Performance Characteristics; Audio Specifications; Connectivity and Power Requirements

- 3 -
Specifi cations
Acoustic
Principle:
Pressure gradient
Polar Pattern: Super-Cardioid
(see graph)
Frequency
Range:
35Hz ~ 20,000Hz
(see graph)
Output
Impedence:
50Ω
Sensitivity: -44dB ± 2 dB re 1V/Pa
(6.3mV @ 94 dB SPL) @ 1 kHz
Equivalent Noise: 23 dB SPL
(A-weighted per IEC651)
Maximum
Output:
5.2dBu
(@1kHz, 1% THD into 1KΩ
load)
Dynamic Range: 118 dB SPL
(A-weighted per IEC651)
Maximum SPL: 141dB
(@1kHz, 1% THD into 1KΩ load)
Signal/Noise: 71 dB SPL
(A-weighted per IEC651)
Power
Requirement:
Phantom P48, P24
Output
Connection:
3-pin XLR
Net Weight:
308g
Dimensions:
Length: 187mm
Width: 47mm
