RODE Microphones M3 - Specifications

- 3 -
Specifi cations
Acoustic Principle:
Permanently Polarised
Condenser
Directional
Pattern:
Cardioid
Frequency Range:
40Hz ~ 20,000Hz
selectable High Pass Filter (HPF)
@ 80Hz 12dB/octave (see graph)
Output
Impedence:
200Ω
Sensitivity:
-40dB ±3dB re 1V/Pa @ 1kHz
(6.3mV/Pa @ 94dB SPL)
Equivalent Noise:
21dBA SPL
(A - weighted per IEC651)
Maximum Output:
+9.22dBu (@ 1% THD into 1kΩ)
Dynamic Range:
121dB (per IEC651)
Maximum SPL:
142dB (@ 1kHz, 1% THD into
1kΩ load)
Signal/Noise:
73dB SPL (@ 1kHz, rel 1Pa)
Power
Requirements:
1.6mA - battery
6.5mA - 48V Phantom Power
Battery Life:
>200 hours
Output
Connection:
3 pin XLR, balanced output
between Pin 2 (+), Pin 3 (-) and
Pin 1 (ground)
Net Weight:
390g (no battery)
Shipping Weight:
1,285g
Dimensions:
Length - 225mm (8
3/4
”)
Diameter - Ø33mm (1
5/16
”)
