RODE Microphones NT2000 - Specifications; Polar Responses

Specifications
• Acoustic Principle: Externally polarized 25 mm (1”) dual diaphragm
• Active Electronics: J-FET impedance converter with bipolar output
buffer.
• Pickup Pattern: Multi-pattern (see graphs)
• Frequency Response: 20 Hz ~ 20 kHz (see graph)
• Output Impedance: 200 Ω
• Sensitivity: -36 dB re 1 Volt/Pascal (16 mV @ 94dB SPL) +/- 2 dB
• Equivalent Noise: 7 dBA SPL (per IEC651, IEC268-15)
• Maximum Output: + 15 dBu (@ 1% THD into 1kΩ)
• Dynamic Range: 136 dB (per IEC651, IEC268-15)
• Maximum SPL: 147 dB (@ 1% THD into 1kΩ)
157 dB (@ 1% THD into 1kΩ) with pad at maximum
• Signal/Noise: 84 dB (per IEC651, IEC268-15)
• Power Requirements: Phantom P48 or P24 Volts.
Polar Responses
Cardioid Omni Fig. 8
