Text box Description – enables to enter custom description for the Authorisation.
Area Details
Parameter Refers to – specifies type of action for the Authorisation. Available values:
 Function – when selected then Authorisation will concern specific input function which can be
selected in the next step
 Function Group – when selected then Authorisation will concern group of functions (e.g. Physical
Access) which can be selected in the next step.
Parameter Action – specifies function or group of functions for the Authorisation.
Area Advanced Options
Option Includes authorisation for all rules – when the option is enabled then the Authorisation will include
all Positive Rules defined in full range i.e. the Authorisation will allow to start action (function) without any
limits in regard of Objects, Access Points and Function Parameters.
Option Includes authorisation for all Access Points – when the option is enabled then the Authorisation
will include Positive Rule for all Access Point i.e. the action (function) can be started without any limits in
regard of Access Points.
Option Includes authorisation for all Function Parameters – when the option is enabled then the
Authorisation will include Positive Rule for all Function Parameters i.e. the action (function) can be started
without any limits in regard of Function Parameters.
Tab Negative Rules
The tab is available when an Advanced Authorisation is created and it enables to define Negative Rules in
regard of Objects, Access Points and Function Parameters. Negative Rules have higher priority than
Positive Rules.
Tab Positive Rules
The tab is available when an Advanced Authorisation is created and it enables to define Positive Rules in
regard of Objects, Access Points and Function Parameters. Positive Rules have lower priority than Negative
Rules.
Schedules
Schedule allows to make the system operation dependent on week day and day time. Schedules can be
applied to multiple functions of the system including Authorisations. Schedule status can be presented on
Output(s) and consequently used to control external devices and systems. Following Schedule types are
available on the level of access controller.
 General Purpose Maintained
 Door Mode
 Time&Attendance Mode
 Authentication Policy
 General Purpose Momentary
Calendars
Calendar allows to alter system operation during holidays and they can also be applied to Authorisations.
Calendars can be defined for many years. Calendar status can be presented on Output(s) and consequently
used to control external devices and systems.
5. SPECIFICATION
Table 7. Specification
Supply voltage
17-22VAC, nominal 18VAC
11.5V-15VDC, nominal 12VDC,
22-26VDC, nominal 24VDC
Current consumption
100 mA for 18VAC (no loads on AUX/TML outputs)
Inputs
Eight parametric inputs (IN1..IN3) internally connected to the power supply
plus through a 5.6kΩ resistor. Approx. 3.5V triggering level for NO and NC
