Relay outputs
Two relay outputs with single NO/NC contact 30V/1.5A rated
Transistor outputs
Six open collector transistor outputs, 15VDC/150mA rated. Max. total current
sink by all outputs up to 3ADC.
Power supply outputs
Two power outputs: 12VDC/0.2A (TML) and 12VDC/1A (AUX)
Distances
1200m for RS485
150m for and RACS CLK/DTA and Wiegand
IP Code
IP20
Environmental class
(acc. to EN 50131-1)
Class I, indoor general conditions, temperature: +5°C to +40°C, relative
humidity: 10 to 95% (no condensation)
Dimensions H x W x D
72 x 175 x 30 mm
Weight
approx. 200g
Certificates
CE
6. ORDERING INFORMATION
All versions of MC16 controller are based on the same hardware and firmware while their functionalities are
specified by license file on memory card. Each version includes various types of controllers. Following
versions of MC16 controllers are available:
 MC16-PAC physical access controllers
 MC16-AZC parking access controllers
 MC16-LRC locker access controllers
 MC16-HRC hotel access and automation controllers
 MC16-EVC and MC16-EVK elevator access controllers
 MC16-BAC building automation controllers
 MC16-IAC alarm zone controllers
 MC16-SVC service controller
Additionally MC16-RAW modules are offered. They require firmware and license file upload for proper
operation as one of available version of MC16 controller.
Parameters which are given in tables below represent maximal values and their actual application usually
requires connection of peripheral devices (MCT, MCX). It is possible to upgrade from lower to higher type of
controller e.g. MC16-PAC-4 -> MC16-PAC-8 and it requires ordering and then uploading of new license.
When license file is ordered then it is necessary to submit MAC address of MC16.
MC16-PAC controllers
MC16-PAC controllers are most widely used controllers in RACS 5 system. They are mainly used to offer
physical access control in premises. Various installation scenarios are presented in AN002 application note.
Particular types of controllers differ by the number of controlled doors (max. 16).
Table 8. MC16-PAC types
Type
MC16-PAC-1
MC16-PAC-2
MC16-PAC-4
MC16-PAC-N
Access Doors
1
2
4
N (≤16)
Access Points
2
4
8
2 x N
Inputs
8
12
24
6 x N
Outputs
8
8
16
4 x N
Function Keys
8
16
32
8 x N
Local Commands
2
4
8
2 x N
