Roger MC16 - Page 49

MC16 Operating Manual 09.01.2020
49/52
Access Zones
2
4
8
2 x N
Alarm Zones
2
4
8
2 x N
Automation Nodes
2
4
8
2 x N
Power Supplies
2
4
8
2 x N
Access Doors per
Access Points
1
1
1
1
MC16-PAC-KIT installation sets
MC16-PAC controllers are offered individually and as elements of MC16-PAC-KITs which simplify RACS 5
system designing and installation. They can to be used to create dispersed system to ensure higher
reliability than centralized system. They provide high resistance to tampering and offer simple and efficient
power supplies. More information on MC16-PAC-KITs is given in their installation manuals.
MC16-AZC controllers
MC16-AZC controllers are mainly used at car parks. They offer the same functionalities as MC16-PAC
controllers and some additional ones in regard of advanced control of occupancy in Access Zone. More
information on MC16-AZC controllers is given in AN031 application note. Particular types of controllers differ
by the number of controlled doors (max. 16).
Table 9. MC16-AZC types
Type
MC16-AZC-1
MC16-AZC-2
MC16-AZC-4
MC16-AZC-N
Access Doors
1
2
4
N (≤16)
Access Points
2
4
8
2 x N
Inputs
8
12
24
6 x N
Outputs
8
8
16
4 x N
Function Keys
4
8
16
4 x N
Local Commands
2
4
8
2 x N
Access Zones
2
4
8
2 x N
Alarm Zones
2
4
8
2 x N
Automation Nodes
2
4
8
2 x N
Power Supplies
2
4
8
2 x N
Access Doors per
Access Points
1
1
1
1
MC16-LRC controllers
MC16-LRC controllers are dedicated to lockers. They offer wired access control based on MCT terminals
and groups of electric locks as well as wireless access control based on RWL-3 terminals. More information
on MC16-LRC controllers is given in AN029 application note. Particular types of controllers differ by the
number of controlled lockers (max. 64).
Table 10. MC16-LRC types
Type
MC16-LRC-8
MC16-LRC-16
MC16-LRC-32
MC16-LRC-64
Access Doors
8
16
32
64
Access Points
2/8*
4/16
8/32
16/64
Inputs
16
32
64
128
