Outputs
16
32
64
128
Function Keys
4
8
16
32
Local Commands
2
4
8
16
Access Zones
0
0
0
0
Alarm Zones
0
0
0
0
Automation Nodes
1
2
2
2
Power Supplies
2
4
8
16
Access Doors per
Access Points
8
16
32
64
* The maximal number of Access Points depends on the type terminals e.g. MC16-LRC-8: 2 x MCT or 8 x
RWL-3
MC16-HRC controllers
MC16-HRC controllers and HR type terminals (e.g. MCT86M-IO-CH-HR ) are dedicated to hotel
applications. More information on MC16-HRC controllers is given in AN033 application note. Particular types
of controllers differ by the number of controlled hotel rooms (max. 4).
Table 11. MC16-HRC types
Typ
MC16-HRC-1
MC16-HRC-2
MC16-HRC-3
MC16-HRC-4
Type
1
2
3
4
Access Doors
2
4
6
8
Access Points
8
12
18
24
Inputs
8
8
12
16
Outputs
4
8
12
16
Function Keys
2
4
6
8
Local Commands
2
4
6
8
Access Zones
2
4
6
8
Alarm Zones
2
4
6
8
Automation Nodes
2
4
6
8
Power Supplies
1
1
1
1
MC16-EVC and MC16EVK controllers
MC16-EVC controllers are dedicated to universal access control in elevators from various manufacturers.
More information on MC16-EVC controllers is given in AN030 application note. Particular types of MC16-
EVC controllers differ by the number of controlled floors (max. 64).
MC16-EVK controllers are dedicated for integration with Kone Destination elevator system from KONE
company. There is one type of MC16-EVK controllers and it enables access control for up to 64 floors.
Table 12. MC16-EVC types
Type
MC16-EVC-8
MC16-EVC-16
MC16-EVC-32
MC16-EVC-64
Access Doors
8
16
32
64
Access Points
1
1
1
1
Inputs
8
8
8
8
