Outputs
16
32
64
128
Function Keys
8
8
8
8
Local Commands
4
4
4
4
Access Zones
0
0
0
0
Alarm Zones
0
0
0
0
Automation Nodes
2
2
2
2
Power Supplies
2
4
8
16
Access Doors per
Access Points
8
16
32
64
MC16-BAC controllers
MC16-BAC controller are dedicated to building automation control by means of Inputs and Outputs operated
on the level of Automation Nodes. Particular types of controllers differ by the number of controlled
Automation Nodes (max. 64).
Table 13. MC16-BAC types
Type
MC16-BAC-8
MC16-BAC-16
MC16-BAC-32
MC16-BAC-64
Access Doors
0
0
0
0
Access Points
4
8
16
32
Inputs
16
32
64
128
Outputs
16
32
64
128
Function Keys
16
32
64
128
Local Commands
4
8
16
32
Access Zones
0
0
0
0
Alarm Zones
0
0
0
0
Automation Nodes
8
16
32
64
Power Supplies
4
8
16
32
MC16-IAC controllers
MC16-IAC controllers are dedicated to advanced control of Alarm Zones in RACS 5 system and they offer
intruder alarm system functionalities. Particular types of controllers differ by the number of controlled Alarm
Zones (max. 16).
Table 14. MC16-IAC types
Type
MC16-IAC-2
MC16-IAC-4
MC16-IAC-8
MC16-IAC-16
Access Doors
0
0
0
0
Access Points
4
8
16
32
Inputs
16
32
64
128
Outputs
16
32
64
128
Function Keys
16
32
64
128
Local Commands
4
8
16
32
