MC16 Operating Manual 09.01.2020
Option Do not allow to exit this zone to not neighboring zone – when the option is enabled then user is
denied access at Exit Point(s) of Access Zone if user’s current zone is not neighboring to the zone which
user attempts to enter. Zones are configured as neighboring by configuration of Access Points. If particular
Access Point is configured as Entry Point to zone A and at the same such Access Point is configured as Exit
Point from zone B than both zones are neighboring. Neighboring options can be used to restrict and enforce
user movement routes in premises.
Tab Entry Points
The tab is available when an Access Zone is created and it enables to select which Access Points will
function as Entry Points to the zone.
Tab Exit Points
The tab is available when an Access Zone is created and it enables to select which Access Points will
function as Exit Points from the zone.
Tab Internal Points
The tab is available when an Access Zone is created and it enables to select which Access Points will
function as Internal Points inside the zone. User can be granted access at Internal Point only if according to
occupancy register such user is inside the zone i.e. user was granted access at Entry Point of the zone.
Tab Inputs
The tab is available when an Access Zone is created and it enables to assign Input(s) to the zone. Input
parameters and functions are listed within the description of Input objects.
Tab Outputs
The tab is available when an Access Zone is created and it enables to assign Output(s) to the zone. Output
parameters and functions are listed within the description of Output objects.
Tab Function Keys
The tab is available when an Access Zone is created and it enables to assign Function Key(s) to the zone.
Function key parameters and functions are listed within the description of Function Key objects.
Tab Local Commands
The tab is available when an Access Zone is created and it enables to assign Local Commands to the zone.
Local Command parameters and functions are listed within the description of Local Command objects.
Tab Group Occupancy Limits
The tab is available when an Access Zone is created and it enables to define Group Occupancy Limits. The
tab is available only for MC16-AZC controllers.
Parameter User Group – enables to select User Group for further configuration of occupancy limits.
Parameter Group Upper Limit – specifies the maximal number of users from certain group inside Access
Zone. When the limit is reached then users are denied access at Entry Point(s). The limit does not apply to
Access Credentials with Master exemption and occupancy exemptions.
Parameter Group Lower Limit – specifies the minimal number of users from certain group inside Access
Zone. When the limit is reached then users are denied access at Exit Point(s). The limit does not apply to
Access Credentials with Master exemption and occupancy exemptions.
Alarm Zones
Alarm Zone represents area with Access Points which are designated as Arming Points. Access Points
belonging to Alarm Zone are armed and disarmed concurrently and current arming mode is presented on
LED indicators of MCT and PRT readers.
Alarm Zones can be applied in integration with intruder alarm systems, for alarm system functionalities of
RACS 5 system and for additional access control. When adequate option is enabled then armed Access
Point can deny access till their disarming while arming/disarming Authorisation can be condifured and
assigned to users individually. More information on Alarm Zones is given in AN027 application note.
Area General
Text box Name – enables to name the zone.
Text box LCD Message – enables to specify zone’s name which will be used on display.
