Roger PR612 - Installation Guide for Roger Access Controllers; Terminals and Connection Diagram

PR612 PR622 PR312EM PR312MF Installation guide Rev.G.doc
2017-09-18
4/16
PR622: 85 x 85 x 27 mm
PR312EM/PR312MF: 152,5 x 46 x 23(35)mm
PR312EM-BK/PR312MF-BK: 152,5 x 46 x 23(35)mm
Weight
PR612/PR622: approx. 120g
PR312EM/PR312EM-BK: approx. 150g
PR312MF/PR312MF-BK: approx. 150g
Certificates
CE
3. INSTALLATION
3.1 Terminals/wires and connection diagram
Table 2. Terminals and wires
Screw terminal
(PR612/PR622)
Wire colour
(PR312EM/
PR312MF)
Description
+12V
Red
12VDC power supply
GND
Black
Ground
IN1
Pink
IN1 input line
IN2
Blue
IN2 input line
IN3
White-yellow
IN3 input line
RS485 A
Brown
RS485 communication bus
RS485 B
Green-white
RS485 communication bus
CLK
White
RACS CLK/DTA comm. bus
DTA
Green
RACS CLK/DTA comm. bus
TMP A
Grey
Tamper switch
TMP B
Yellow
Tamper switch
IO1
Yellow-brown
IO1 output line
IO2
Green-brown
IO2 output line
REL1-NC
Grey-pink
REL1 relay output (NC)
REL1-COM
Red-blue
REL1 relay common terminal
REL1-NO
Violet
REL1 relay output (NO)
