Rogerblack Cross Trainer - Exploded Parts List

Part
Description
Qty.
Part
Description
Qty.
1
Main Frame
1
30
Ø38×2mm Nylon Washer
2
2
Foot Bar
2
31
M8 x 25mm Hex Bolt
6
3L
Left Handrail Arm
1
32
Ø8mm Washer
2
3R
Right Handrail Arm
1
33
M8x45mm Carriage Bolt
4
4L
Left Handrail
1
34
Ø25mm Corrugated Washer
2
4R
Right Handrail
1
35
Ø38×Ø25mm Nylon Bushing
2
5
Front Post
1
36
L/Front Handle Rail Cover
1
6
Handle Bar
1
37
M8 Axle Bolt
2
7
Computer
1
38
Powder Metallurgy Bushing
4
8
Handle Grip
2
39
ST4.2 x 12mm Dome Head Screw
26
9
Hand Grip Pulse Sensor
2
40
Left Linkage Cover
2
10
Ø22×1.5mm Cone End Cap
2
41
Right Linkage Cover
2
11
ST4.2x20mm Philips Screw
2
42
Foot Pedal
2
12
M8 x 40mm Allen Bolt
1
43
Crank Cover
2
13
ST4.2 x 15mm Philips Screw
19
44
M6 Knob
4
14
M5 x 10mm Dome Head
Philips Bolt
4
45
2mm Big Washer 1
2
15
Front Post Rear Cover
1
46
Nylon Washer
2
16
Front Post Front Cover
1
47
Crank Powder Metallurgy Bushing
4
17
Tension Control Knob
1
48
Ø19mm Corrugated Washer
2
18
M5x50mm Bolt
1
49
Inner Crank Nylon Bushing
2
19
Front Linkage Axle
1
50
Ø60mm Front Wheel Foot
2
20
M8x15mm Allen Bolt
6
51
Base Stabilizer
2
21
Ø25×Ø9×R30mm Arc Washer
6
52
Ø11×R34mm Arc Washer
4
22
Ø8mm Spring Washer
8
53
Ø38×1.5mm Cone End Cap
2
23
Ø10mm Spring Washer
4
54
M10 x 20mm Allen Bolt
4
24
Handrail Foam Grip
2
55
ST4.8 x 12mm Dome Head Philips
Screw
2
25
L/Rear Handrail Cover
1
56
Water Bottle Stand
1
26
Ø38×Ø32mm Sleeve
2
57
Left Front Cover
1
27
M8 Aircraft Nut
10
58
Idle Wheel Axle
1
28
Ø25×Ø8×R19mm Arc Washer
4
59
Ø10mm Washer
2
29
Bushing
4
60
Idle Wheel Bracket
1
Exploded Parts List
21
