Measurements
R&S
®
RTM3000
148User Manual 1335.9090.02 ─ 09
Figure 8-1: Results of four active measurements
Measurement errors are indicated as follows:
? A result cannot be determined. Adjust the horizontal and vertical settings if
the instrument cannot measure.
"clipping+" or "clipping-" The measurement result is outside the measurement range and clipping
occurs. Adjust the vertical scale to get valid results.
n/a No valid waveform is available, for example, if the source waveform is off.
Remote commands are described in:
●
Chapter 17.7.2.2, "Measurements results", on page 521
8.2.1.1 Statistics
In addition to the current measurement results, you can enable a statistic evaluation. It
returns the current, minimum and maximum measurement values, the average and
standard deviation, and the number of measured waveforms. The results are shown in
a separate tab below the grid. If the cursor measurement is active simultaneously, its
results are shown beside the statistic results.
Automatic measurements
