Remote control commands
R&S
®
RTM3000
520User Manual 1335.9090.02 ─ 09
Example:
MEAS2:MAIN DELay
MEAS2:SOUR CH1,CH2
MEAS2:DEL:SLOP POS,NEG
MEAS2:DEL:DIR NEAR,FRFI
Configures a delay measurement on measurements place 2. It
measures the time delay between the positive edge of channel 1
that is nearest to the trigger, and the next to the right negative
edge on channel 2.
Example:
MEAS3:MAIN DTOTrigger
MEAS3:SOUR CH1
MEAS3:DEL:SLOP POS,NEG
MEAS3:DEL:DIR FRFI,FRFI
Configures a delay to trigger measurement on measurements
place 3. It measures the time delay between the trigger and the
next to the right positive edge of channel 1. The second values
for slope and direction are ignored.
MEASurement<m>:DELay:MARKer
<MarkerVisible>
If ON, the markers show the edge, the measured point on the edge, and the direction
in which the edge is detected.
Suffix:
<m>
.
1..8
Parameters:
<MarkerVisible> ON | OFF
*RST: OFF
MEASurement<m>:STATistics[:ENABle] <StatisticEnable>
Activates or deactivates the statistical evaluation for all active measurements.
Suffix:
<m>
.
The suffix is irrelevant.
Parameters:
<StatisticEnable> ON | OFF
*RST: OFF
MEASurement<m>:STATistics:RESet
Deletes the statistical results for all measurements, and starts a new statistical evalua-
tion if the acquisition is running. The waveform count is set to 0 and all measurement
values are set to NAN.
Suffix:
<m>
.
The suffix is irrelevant.
Usage: Event
Measurements
