Roland Camm-1 GR2-540 User Manual

Setting item Settings Notes
[Printer] Select the machine model.
[Artboards] Select the [Ignore Artboards] check
box.
Clear this check box if the artboard size is suited to the
cutting data.
[Placement] Select the lower-left point.
5. Press [Setup].
The [Print] window appears.
6. Click [Preferences].
The [Printing Preferences] window appears.
7. Select the [Cutter] tab and change the cutting conditions ( ).
If necessary, configure the other cutting settings ( ).
Performing Cutting
Basic Printing and Cutting 75

Roland Camm-1 GR2-540 Specifications

General

Connectivity	USB 2.0, Ethernet
Cutting Method	Media-moving method
Power Supply	AC 100 to 240 V ±10%, 50/60 Hz
Power Requirements	AC 100 to 240 V ±10%, 50/60 Hz
Cutting Width	54 inches
Maximum Cutting Speed	1, 485 mm/s
Software Resolution	0.025 mm/step
Weight	187 lbs
Usable Tools	Cutting blade, plotting pen
Distance Accuracy	±0.2% or 0.3 mm (0.012 in), whichever is greater
Repeatability Accuracy	±0.1 mm
Alignment Accuracy for Print & Cut	±0.04 inches
Operating Temperature	41-95°F (5-35°C)
Operating Humidity	35 to 80% RH (non-condensing)
Weight (with stand)	187 lbs
Blade Type	Roland CAMM-1 series blades
Resolution	0.025 mm/step
