Names of Things and What They Do
fig.Rearpanel-e.eps
MIDI In/Out connectors
You can connect these to external MIDI devices to
transfer performance data (p. 84).
Input jacks (L/Mono, R)
Here you can connect an audio device or another
electronic musical instrument, and listen to the connected
device through the DP-990’s speakers (p. 83).
Output jacks (L/Mono, R)
You can connect an audio device or external powered
speakers here to reproduce the DP-990’s sound (p. 82).
Dc In (DC Inlet)
Connect the supplied AC adaptor here (p. 18).
Cord hook
Use this to fix in place the cord from the supplied AC
adaptor (p. 18).
Pedal connector
Connect the pedal cord of the dedicated stand to this
connector (p. 18).
Rear Panel
20 21 22
23 24 25
20
21
22
23
24
25
