80
Main specifications
● USB Port
Mini-B Type Connector
USB 1.1 or 2.0 High Speed (Mass Storage Class)
● Control Sync Jack
Stereo Mini Type Jack
Word clock sync and start/stop remote control of 2 units
* Remote control function does not guarantee the exact same REC
start time
• 3-Band EQ
• 6-Band Graphic EQ
•Noise Gate
•Enhancer
•Comp & DeEsser
• MS Mic Mixing
* Effects can be during recording and playback
* Effects are not available while sample rate is set to 192kHz
•Power Switch
•Hold Switch
•Input SENS Knobs
•Input Level Knobs
• Monitor Level knob
• Phantom Power Switches: CH1/2/ 3/4
• Limiter Switch
• Low cut switch
•Scrub (Value)
• Transport Buttons: PREV (REW), NEXT (FWD), STOP,
• PLAY/PAUSE, REC
• Marker Buttons: CLEAR, , , MARK
•Effect button
•System button
• Display Button
•A-B Repeat Button
● Display
128 x 64 organic EL
● Power Supply
AC adaptor (PSB-1U)
AA type battery x 4 (Alkaline or NiMH only)
Battery life
When using alkaline batteries, 44.1 kHz, 16-bit, stereo, with
phantom power off
● Current Draw
1.2A
● Dimension
157 mm(W) x 183 mm(D) x 61 mm(H)
6-3/16”(W) x 7-1/4”(D) x 2-7/16”(H)
● Weight
1.3 kg including batteries and SD me
2 lbs 14 oz
* 0dBu = 0.775 Vrms
962a
* In the interest of product improvement, the specifications and/or
appearance of this unit are subject to change without prior notice.
Other Terminals
Built-In Effects
Control
Others
Continuous playback approximately 4.0 hours
Continuous recording approximately 4.0 hours
