SWITCH TEST
Pressing the button 1, you enter the Switch test:
Press the buttons on the control panel one by one in sequence. The display visualizes the name
of the button pressed and you hear a sound.
fter pressing each button the corresponding led lights up.
The switch test finishes when all the control panel’s buttons have been pressed and the system
goes automatically back to the main menu (Sw, Led, Lcd).
If you want to exit before pressing all the buttons, you can go back to the main menu (Sw, Led,
Lcd) by keeping the buttons 1 and 0 pressed at the same time.
LED TEST
Pressing button 2, the display visualizes :
TEST LED
The LEDS light up in sequence. At the end of the sequence they are all on.
To exit, press button 0 (Exit).
LCD TEST
Pressing button 3, the display visualizes:
ON OFF
Pressing button 1 (ON), the display visualizes:
Press button 0 (Exit) to get back to the previous menu page.
Pressing button 2, the display shows the characters and symbols that are visualized when off.
Press 0 (Exit) 3 times to go back to the main menu.
