Jul. 2015 JD-XA
# 5100042732 PANEL R SHEET ASSY 1
* This unit includes the following parts.
# ******** PANEL R BOARD 1
# ******** ENCODER4 BOARD 1
PWB ASSY
DIODE
5100019998 LED DKA13SR053G(F5229831R0) 6
# 5100041421 LED WW-BIS190TS-G 11
5100036746 LED WW-FCE50TC-Q1(BTF) 16
5100036498 LED WW-GIS190TS-G 14
5100036720 LED WW-OR190TS-J 146
POTENTIOMETER
# 5100041025 ENCODER EC18AGA20402 4
04901712 ROTARY POTENTIOMETER RK09K1110D4S 1
# 5100041032 ROTARY POTENTIOMETER XV09223NPV25F972Z10K/I 21
# 5100041031 ROTARY POTENTIOMETER XV09223NPV25F972Z10KCC/I 7
5100037657 SLIDE POTENTIOMETER C3080G1AV1B103BA00B3 15
# 5100043757 SLIDE POTENTIOMETER C3080G1AV1B103BA01BF 3
WIRING, CABLE
# 5100046504 FLAT CABLE SML2CD-14X70-BDX8(BL)-P1.0-S4 4
# 5100046505 FLAT CABLE SML2CD-14X80-BDX8(BL)-P1.0-S4 1
5100022474 FLAT CABLE SML2CD-20X40-BDX8(BL)-P1.0 1
# 5100046508 FLAT CABLE SML2CD-22X550-BDX8(BL)-P1.0-S 1
# 5100046507 FLAT CABLE SML2CD-24X360-BDX8(BL)-P1.0-S 1
# 5100046509 FLAT CABLE SML2CD-24X40-BDX8(BL)-P1.0-S4 1
# 5100046506 FLAT CABLE SML2CD-38X40-BDX8(BL)-P1.0-S4 1
# 5100046512 WIRING 1061#28 14X450-PHR-PHR-F 1
5100039038 WIRING 1061#28 3X80-PHR-PHR-F 1
# 5100045471 WIRING 1061#28 4X100-PHR-PHR-F 1
5100043932 WIRING 1061#28 4X60-PHR-PHR-F 2
# 5100046510 WIRING 1061#28 7X110-PHR-PHR-F 1
# 5100046511 WIRING 1061#28 8X40-PHR-PHR-F 1
# 5100046513 WIRING 1061#28 8X450-PHR-PHR-F 1
04569890 WIRING CA ASSY 26WAY 400MM W/2 HX2 1
SCREWS
5100034002 SCREW M3X12 PAN MACHINE W/SMW+PW BZC 1
40454856 SCREW M4X10 BINDING MACHINE NI 1
5100038406 SCREW 2.6X6 BINDING TAPTITE P BZC 4
40011312 SCREW 3X8 BINDING TAPTITE P FE BZC 98
96
# 5100044863 SCREW 3X8 HEX SOCKET HEAD TAPTITE B BZC 10
40011334 SCREW 3X12 BINDING TAPTITE P FE BZC 12
14
40011323 SCREW 3X10 BINDING TAPTITE P BZC 4
40012345 SCREW 4X10 BINDING TAPTITE B BZC 4
40012490 SCREW 4X10 BINDING TAPTITE P BZC 15
MISCELLANEOUS
5100035565 BENDER PB-H0301-BK 1
# 5100042659 BENDER WHEEL ASSY 1
5100027106 CORD HOOK 40516-014 1
# 5100044793 JD BADGE 1
# 5100044791 ROLAND BADGE 1
5100037792 R-KNOB ESCUTCHEON CLR 28
5100037876 S-KNOB ESCUTCHEON CLR 18
12359137 RUBBER FOOT SJ-5012 BLK 5
5100032738 TERMINAL PCB-12(M4) 1
5100003695 TERMINAL PCB-12 1
# 5100044851 INSULATING SHEET 1
5100044220 LCD SHIELD SHEET 1
# 5100046310 SHIELD SHEET 1
5100010674 DISPLAY CUSHION 1
40120967 COATING CLIP CS-3 1
5100027814 LOCKING CABLE TIE CV-100V0K 4
40122812 ACETATE TAPE NITTO #5 BLACK W15MM 30M -
40122490 DOUBLE-FACED TAPE #500 W5MM 20M 40P -
40122534 DOUBLE-FACED TAPE #500 W3MM 20M 136P -
40122645 NITTO FILAMENT TAPE #3883 W19MM 50M 60P (CM) -
