20
Jul. 2015 JD-XA
Parts List
fig.-part1-e.eps
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons, parts with parts code ******** cannot be supplied
as service parts.
• Supply is prohibited due to copyright restrictions.
• It is carried in electronic data on the Roland web site.
• The part is made to order (at current market price).
• It can be replaced with an article on the market. (battery or etc.)
• It is a package or an accessory irrelevant to the function maintenance of the main body.
• A number of circuit boards are grouped together and supplied as a single circuit board (under a different part code).
• Reissuance is restricted.
• It is supplied as an assembled part
(under a different part code).
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
CASING
# 5100042382 TOP CASE 1
# 5100042383 BOTTOM CASE 1
# 5100042385 FRONT CORNER COVER 1
# 5100042386 REAR CORNER COVER 1
# 5100042384 SIDE COVER 2
# 5100042388 PANEL SHEET A 1
# 5100042391 PANEL SHEET B 1
# 5100042392 PANEL SHEET C 1
# 5100042393 PANEL SHEET D 1
# 5100042394 BENDER PANEL SHEET 1
CHASSIS
# 5100042387 CENTER HOLDER 4
KNOB, BUTTON
# 5100044852 J S-KNOB M BLK/RED 18
# 5100042398 ZT R-KNOB SF BLK/SLV 27
# 5100046586 ZT R-KNOB SF BLK/RED 1
# 5100042401 ZT R-KNOB MF BLK/SLV 4
# 5100042396 ZT C-KEYTOP SX1H BLK 11
# 5100042395 ZT C-KEYTOP SD1H BLK/CLR 58
# 5100042397 ZT S-KEYTOP SD1H BLK/CLR 16
5100037825 G S-BUTTON BLK (710-12058-15-00) 1
SWITCH
02781634 TACT SWITCH SKRGAED010 85
04904123 PUSH SWITCH AC POWER SUPPLY 400-07040-01-00(PWL-2P2T-6SBP 1
JACK, EXT TERMINAL
02456390 3.5MM JACK STEREO YKB21-5290 4
13449275 6.5MM JACK YKB21-5074 4
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 4
02900312 DC JACK HEC0470-01-640 1
13429676 MIDI CONNECTOR YKF51-5048V(TWIN) 1
5100014678 CANNON CONNECTOR CT/PJ-02-EP 1
04459190 USB CONNECTOR A TYPE FEMALE YKF45-0033N 1
5100010665 USB CONNECTOR B TYPE FEMALE 2549A-04G2T(610-02001-04-00) 1
DISPLAY UNIT
5100041314 LCD 221-1162-2123 1
KEYBOARD ASSY
5100009856 KEYBOARD ASSY MSK-249 AFT W/O CABLE (990-06022-10-02) 1
PWB ASSY
# 5100042729 MAIN BOARD ASSY 1
# 5100042730 ANALOG JACK BOARD ASSY 1
# 5100042731 PANEL L SHEET ASSY 1
* This unit includes the following parts.
# ******** PANEL L BOARD 1
# ******** SIDE BOARD 1
# ******** WHEEL BOARD 1
# ******** ENCODER1 BOARD 1
# ******** ENCODER2 BOARD 1
# ******** ENCODER3 BOARD 1
# ******** AFTER BOARD 1
To Next Page
