Roland Jupiter-Xm User Manual

15
Splitting the Keyboard to Play Different
Sounds (Split)
1. Press the [FUNCTION] button to make it light.
Chooses function mode.
2. Press the [15] button.
Split turns on. The part 1 tone sounds in the right-hand region of
the keyboard, and the part 2 tone sounds in the left-hand region.
To return to the original state, press the [15] button once again in
function mode.
* If you want to change the split point, enter function mode, then hold
down the [15] button and press the desired key; alternatively, you can use
SCENE ZONE EDIT to set the KEY RANGE. For details, refer to “Reference
Manual” (PDF).
Layering Two Sounds (Dual)
1. Press the [FUNCTION] button to make it light.
Chooses function mode.
2. Press the [16] button.
Dual is turned on. This layers the part 1 tone with the part 2 tone,
so that they are heard together.
To return to the original state, press the [16] button once again in
function mode.
* If you hold down the [SHIFT] button and press the [DUAL] button to turn
Dual on, settings are automatically made so that part 1 is output from L
and part 2 is output from R.
Transposing the Keyboard in Octave
Units (Octave)
1. Press the OCTAVE [DOWN] [UP] button.
To return to the original state, press the OCTAVE [DOWN] and [UP]
buttons.
Transposing the Keyboard in Semitone
Steps (Transpose)
1. Hold down the [TRANSPOSE] button and press the OCTAVE
[DOWN] [UP] button.
To return to the original state, hold down the [TRANSPOSE] button
and press the OCTAVE [DOWN] button and [UP] button.
Playing Single Notes (Monophonic)
1. Press the [FUNCTION] button to make it light.
Chooses function mode.
2. Press the [11] button.
Mono turns on.
To return to the original state, press the [11] button once again in
function mode.
Layering the Same Tone to Thicken the
Sound (Unison)
1. Press the [FUNCTION] button to make it light.
Chooses function mode.
2. Press the [12] button.
Unison turns on.
To return to the original state, press the [12] button once again in
function mode.
Preventing Dynamics Changes in Your
Performance (Velocity Off)
1. Press the [FUNCTION] button to make it light.
Chooses function mode.
2. Press the [13] button.
The velocity off setting is enabled. Your keyboard dynamics will not
affect the sound.
To return to the original state, press the [13] button once again in
function mode.
Smoothly Changing the Pitch (Portamento)
1. Press the [FUNCTION] button to make it light.
Chooses function mode.
2. Press the [14] button.
Portamento turns on.
To return to the original state, press the [14] button once again in
function mode.
* In function mode, you can hold down the [SHIFT] button and press the
[14] button to access the portamento time setting screen.
Using Performance Functions

Roland Jupiter-Xm Specifications

Power

dc voltage	12 V
current draw	1, 500 mA
battery type	Ni-MH battery (AA, HR6) x 8
battery life	approximately 3.5 hours

Display

display type	Graphic LCD
display resolution	128 x 64 dots

Audio

speaker amplifier power	4 W x 2
full range speaker size	3.5 x 8 cm x 2
tweeter size	2 cm x 2

Weight and Dimensions

weight	4.4 kg, 9 lbs 12 oz
width	576 mm, 22-11/16 inches
depth	308 mm, 12-1/8 inches
height	93 mm, 3-11/16 inches
