JV-1010 Feb. 1999
5
00567212 RPC05T 332 J MTL.FILM RESISTOR on MAIN 2
00567245 RPC05T 472 J MTL.FILM RESISTOR on MAIN 3
00567301 RPC05T 153 J MTL.FILM RESISTOR on MAIN 1
00567378 RPC05T 473 J MTL.FILM RESISTOR on MAIN 1
00567556 RPC05T 105 J MTL.FILM RESISTOR on MAIN 1
01011256 SR73K2ETD 0.47JOHM 1/2W MTL.FILM RESISTOR on MAIN 1
15399429 RPC10T 223 J 1/10W MTL.FILM RESISTOR on MAIN 1
15399405 RPC10T 222 J 1/10W MTL.FILM RESISTOR on MAIN 1
15399301 RPC10T 0R0 J MTL.FILM RESISTOR on MAIN 6
15399421 RPC10T 103 J 1/10W MTL.FILM RESISTOR on MAIN 1
15399377 RPC10T 151 J MTL.FILM RESISTOR on MAIN 9
15399397 RPC10T 102 J 1/10W MTL.FILM RESISTOR on MAIN 2
00567023 RPC05T 101 J MTL.FILM RESISTOR on MAIN 8
00567289 RPC05T 103 J MTL.FILM RESISTOR on MAIN 17
00567412 RPC05T 104 J MTL.FILM RESISTOR on MAIN 1
15399385 RPC10T 331 J MTL.FILM RESISTOR on MAIN 2
15399381 RPC10T 221 J 1/10W MTL.FILM RESISTOR on MAIN 1
00566867 RPC05T 100 J MTL.FILM RESISTOR on MAIN 2
15409113 EXBV8V103JV RESISTOR ARRAY on MAIN 9
01013923 EXBV8V100JV RESISTOR ARRAY on MAIN 6
01457145 EXBE10C103J RESISTER ARRAY on MAIN 3
00126112 EXBV8V101JV RESISTOR ARRAY on MAIN 7
POTENTIOMETER
# 01789523 RK0971214 9M/M ROTARY POT. VR1 on MAIN 1
CAPACITOR
# 15359433R0 GRM40B561K50PT10 CERAMIC CAPACITOR on MAIN 2
# 15359437R0 GRM40B122K50PT10 CERAMIC CAPACITOR on MAIN 2
15359206R0 GRM40F104Z25PT10 CERAMIC CAPACITOR on MAIN 2
# 01672412 GRM39CH150J50PT CERAMIC CAPACITOR on MAIN 2
01672423 GRM40CH101J50PT CERAMIC CAPACITOR on MAIN 4
# 01675190 GRM39CH220J50PT CERAMIC CAPACITOR on MAIN 2
# 01675256 GRM39CH680J50PT CERAMIC CAPACITOR on MAIN 2
01675367 GRM39CH471J50PT CERAMIC CAPACITOR on MAIN 1
01675278 GRM39CH101J50PT CERAMIC CAPACITOR on MAIN 18
00567823 GRM39B102K50PT CERAMIC CAPACITOR on MAIN 3
00567978 GRM39F104Z25PT CERAMIC CAPACITOR on MAIN 65
01349312 GRM39F105Z10PT CERAMIC CAPACITOR on MAIN 1
# 00567834 GRM39B122K50PT CERAMIC CAPACITOR on MAIN 3
00567945 GRM39B103K50PT CERAMIC CAPACITOR on MAIN 3
# 13519627M0 ECKR1H271KB5 CERAMIC CAPACITOR on MAIN 1
# 01675167 GRM39CH100D50PT CERAMIC CAPACITOR on MAIN 1
13549255M0 ECQ-B1H102JF3 POLYEST.CAPACITOR on MAIN 2
13549341 ECQ-B1H101KF3 POLYEST. CAPACITOR on MAIN 2
# 13639566J0 SME25VB10TP CHEMICAL CAPACITOR on MAIN 4
13639574 SME25VB4R7TP CHEMICAL CAPACITOR on MAIN 7
13639602J0 SME50VB1TP CHEMICAL CAPACITOR on MAIN 1
13639513J0 SME6.3VB220TP 220UF/6.3V CHEMICAL CAPACITOR on MAIN 2
13649646 SME16VB470TP 470UF/16V CHEMICAL CAPACITOR on MAIN 1
13639514M0 ECA0JM331B CHEMICAL CAPASITOR on MAIN 2
13629624S0 6SC10M+T (OS) 6.3V10 CHEMICAL CAPACITOR on MAIN 1
13639550J0 SME16VB100TP 100UF/16V CHEMICAL CAPACITOR on MAIN 1
13639569J0 SME25VB47TP CHEMICAL CAPACITOR on MAIN 16
INDUCTOR, COIL, FILTER
01346089 SBC3-331-551 CHOKE COIL on MAIN 2
00237212 SH-202 CHOKE COIL on MAIN 1
12449347 EXC ELDR35V FERRITE-BEAD on MAIN 6
01340834 EXCML20A390 FERRITE-BEAD on MAIN 1
01455623 N2012Z102T01 FERRITE-BEAD on MAIN 12
CRYSTAL, RESONATOR
00901912 MA-406 24.576MHZ TE24 CRYSTAL X1 on MAIN 1
01126267 MA-406 7.056MHZ CRYSTAL X2 on MAIN 1
ENCODER
# 01785790 RK09710EL-5R4611 ROTARY ENCODER EN1 on MAIN 1
CONNECTOR
13369600 52147-0510(5P) CONNECTOR CN3,5 on MAIN 2
13369936 53253-1410 (2MM PITCH) CONNECTOR CN7 on MAIN 1
13429833 52411-0402 40P CONNECTOR CN1 on MAIN 1
13429294 51048-0500(5P) CABLE HOLDER CN2 on D-SW 1
SCREW
40011090 SCREW M3X6 BINDING TAPTITE B BZC 8
40011056 SCREW M3X6 BINDING TAPTITE B ZC 6
40011145 SCREW M3X6 FLAT TAPTITE B FE BZC 2
40011312 SCREW M3X8 BINDING P-TITE FE BZC 2
40011490 SCREW M3X6 PAN MACHINE W/SW BZC 1
PACKING
00892734 ADAPTOR PAD 1
# 01891090 PAD 1
00906423 MODULE PAD L SS-55ST 1
00906445 MODULE PAD R SC-55ST 1
# 01785434 PACKING CASE 1
# 01897990 OUTER PACKING CASE OUTER 1
MISCELIANEOUS
12569249 LITHIUM BATTERY CR2032 220MAH/3V 1
22365714 CORD HOOK 236-714 1
01785467 ISOLATOR LED MASK 1
# 01789534 PWB SPACER RSPS-6L 1
12189815 BATTERY HOLDER BH-32 BT1 on MAIN 1
ACCESSORIES (STANDARD)
00905756 AC ADAPTOR ACI-100C 1
00905767 AC ADAPTOR ACI-120C 1
01018312 AC ADAPTOR ACI-230C 1
01458278 AC ADAPTOR ACB-230E 230VE(DC9V.1200MA) 1
12449549 AC ADAPTOR ACB-240A 1
00564612 FOOT C4305+N#500 4
01788623 CD-ROM (EXP ONLY) SOUND EDITOR+JV-1010 MANUAL 1
Contents of CD-ROM
• SoundDriver JV/XP
• MIDI Driver
• JV/1010 Reference Manual
• Licence Agreement
23485228 MIDI CABLE 348-228 1M (BLACK) 1
00908323 ORIGINAL CONNECT CORD RCA PIN 1.0M 4ADPT 1
# 71451067 OWNER'S MANUAL JAPANESE 1
# 71451078 OWNER'S MANUAL ENGLISH 1
40232334 (Japan Only) 1
/ボリューム
/コンデンサー
/インダクター､コイル､フィルター
/クリスタル､発振子
/エンコーダー
/コネクター
/ねじ類
/梱包材
/その他
/標準付属品
（海外用）
保証書セット
