Roland SOLJET PROIII XC-540 User Manual

6-2 Setting the Location for Starting Output
Setting the Output-start Location
Procedure

Use to
move the cutting carriage.
Align the center of the blade with the new
output-start location.

Press .
Description
You can use to set the output-start location anywhere you want. Note, however, that this set-
ting must be made for each individual page. When the printing of one page nishes, the output-start
location returns to its default value. When the location has been set, lights up. Also, the screen
displays the printable width at the set location.
When using the take-up unit, never use . Doing so may cause the take-up unit to pull the media
with undue force, resulting in an error or malfunction.
Base point
Chapter 6 Feature Reference
Chapter 6 Feature Reference
91

Roland SOLJET PROIII XC-540 Specifications

General

Maximum Resolution	1440 dpi
Print Speed	Up to 32.3 m²/h (347.6 sq. ft./h)
Print Technology	Piezo inkjet
Media Width	210 to 1371 mm
Colors	CMYK
Media Handling	Roll feed
Connectivity	USB, Ethernet
Printing Technology	Piezoelectric inkjet
Print Resolution	1440 dpi
Maximum Print Width	1346 mm
Ink Colors	CMYK
Media Thickness	Maximum 1.0 mm
Interface	USB, Ethernet
Power Requirements	AC 100 to 120 V ±10% 50/60 Hz or AC 220 to 240 V ±10% 50/60 Hz
Ink Type	Eco-Sol MAX
