MIDI Implementation
3
General Purpose Controller 2 (Controller number 17)
Status 2nd byte 3rd byte
BnH 11H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* Only the channel assigned to the drum part can be received.
* Setting [SETUP] - [MIDI] - [CTRL] HH Pedal CC to “GENERAL 2” changes the hi-hat
control pedal position.
* The strike position of the pad corresponding to the note number received changes
immediately after [SETUP] - [MIDI] - [CTRL] Snare CC (for the SNARE pad head and
rim), Ride CC (for the RIDE pad bow), or Toms/AUXs CC (for head and rim of TOM 1–4,
AUX 1–4 pads) is set to “GENERAL 2.”
* During recording, the sequencer data is recorded to the TD-30 in accordance
with the above settings as “HH Pedal CC messages,” “Snare CC messages,” “Ride CC
messages,” and “Toms/AUXs CC messages.”
General Purpose Controller 3 (Controller number 18)
Status 2nd byte 3rd byte
BnH 12H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* Only the channel assigned to the drum part can be received.
* Setting [SETUP] - [MIDI] - [CTRL] HH Pedal CC to “GENERAL 3” changes the hi-hat
control pedal position.
* The strike position of the pad corresponding to the note number received changes
immediately after [SETUP] - [MIDI] - [CTRL] Snare CC (for the SNARE pad head and
rim), Ride CC (for the RIDE pad bow), or Toms/AUXs CC (for head and rim of TOM 1–4,
AUX 1–4 pads) is set to “GENERAL 3.”
* During recording, the sequencer data is recorded to the TD-30 in accordance
with the above settings as “HH Pedal CC messages,” “Snare CC messages,” “Ride CC
messages,” and “Toms/AUXs CC messages.”
General Purpose Controller 4 (Controller number 19)
Status 2nd byte 3rd byte
BnH 13H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
Pedal position: open to closed
Head strike position: center to perimeter
Rim strike position: deep to shallow
* Only the channel assigned to the drum part can be received.
* Setting [SETUP] - [MIDI] - [CTRL] HH Pedal CC to “GENERAL 4” changes the hi-hat
control pedal position.
* The strike position of the pad corresponding to the note number received changes
immediately after [SETUP] - [MIDI] - [CTRL] Snare CC (for the SNARE pad head and
rim), Ride CC (for the RIDE pad bow), or Toms/AUXs CC (for head and rim of TOM 1–4,
AUX 1–4 pads) is set to “GENERAL 4.”
* During recording, the sequencer data is recorded to the TD-30 in accordance
with the above settings as “HH Pedal CC messages,” “Snare CC messages,” “Ride CC
messages,” and “Toms/AUXs CC messages.”
Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
0-63 = OFF, 64-127 = ON
* Only the channels assigned to the backing part can be received.
* When recording, this is recorded in the sequencer data itself.
Eect 1 Depth (Reverb Send Level)
(Controller number 91)
Status 2nd byte 3rd byte
BnH 5BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Reverb send level: 00H - 7FH (0 - 127)
* Only the channels assigned to the backing part can be received.
* Changes the reverb send level ([PATTERN] - [PART] - [MIXER] - [REV SND]) for the part.
Not indicated in the display.
* Not recorded in the sequencer.
Eect 2 Depth (Chorus Send Level)
(Controller number 93)
Status 2nd byte 3rd byte
BnH 5DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Chorus send level: 00H - 7FH (0 - 127)
* Only the channels assigned to the backing part can be received.
* Changes the reverb send level ([PATTERN] - [PART] - [MIXER] - [REV SND]) for the part.
Not indicated in the display.
* Not recorded in the sequencer.
