Roland V-1SDI Reference Manual

MIDI Implementation
12
{ Undened (Controller Number 25)
Status 2nd Byte 3rd Byte
BnH 19H xxH
* This turns the [SPLIT] button on/o.
{ Undened (Controller Number 26)
Status 2nd Byte 3rd Byte
BnH 1AH vvH
* This controls the state of the [OUTPUT FADE] knob.
{ Undened (Controller Number 27)
Status 2nd Byte 3rd Byte
BnH 1BH xxH
* This turns the [FREEZE] button on/o.
{ Undened (Controller Number 28)
Status 2nd Byte 3rd Byte
BnH 1CH vvH
* This controls the state of the [CONTROL 1] knob.
{ Undened (Controller Number 29)
Status 2nd Byte 3rd Byte
BnH 1DH vvH
* This controls the state of the [CONTROL 2] knob.
z Program Change
Status 2nd Byte
CnH ppH
pp= Program Number: 00H–7FH (1–128)
* Select video input or memory number along with the bank select. For information
on control for bank select and program change, refer to “Bank Select”(p. 11)
* Unselectable program change will be ignored.
System Exclusive Messages
Status Data Byte Status
F0H iiH,ddH,...,eeH F7H
F0H: Status of system exclusive message
ii= ID number: This is the ID to recognize manufacturer of the exclusive
message (manufacturer ID). The manufacturer ID of Roland
is 41H. The ID numbers of 7EH and 7FH are expansion of MID
standards and used as universal non-realtime message (7EH) of
universal realtime message (7FH).
dd,...,ee= data: 00H–7FH (0–127)
F7H: EOX (end of exclusive)
z Data Request 1 (RQ1)
This is the message to request of “send data” to the connected device. Specify data
type and amount using address and size. When this is received, the unit sends the
requested data as “Data Set 1 (DT1)” message in case the unit is in status where the
sending of data is possible and requested address and size are appropriate. If not, the
unit sends nothing.
Status Data Byte Status
F0H 41H, 10H, 00H, 00H, 00H, 31H, 11H, aaH, F7H
bbH, ccH, ssH, ttH, uuH, sum
Byte Explanation
F0H Exclusive Status
41H Manufacturer ID (Roland)
10H Device ID
00H 1st byte of model ID (V-1SDI)
00H 2nd byte of model ID (V-1SDI)
00H 3rd byte of model ID (V-1SDI)
31H 4th byte of model ID (V-1SDI)
11H Command ID (RQ1)
aaH Address upper byte
bbH Address middle byte
ccH Address lower byte
ssH Size upper byte
ttH Size middle byte
uuH Size lower byte
sum Checksum
F7H EOX (end of exclusive)
* Depending on the data type, the amount of single-time transmission is specied.
It is necessary to execute data request according to the specied rst address and
size. Refer to the “3. Parameter Address Map” (p. 14) for address and size.
* See “Example of an Exclusive Message and Calculating a Checksum” (p. 23) for
checksum.
z Data Set 1 (DT1)
This is the message of actual data transmission. Use this when you want to set data
to the unit.
Status Data Byte Status
F0H 41H, 10H, 00H, 00H, 00H, 31H, 12H, aaH, F7H
bbH, ccH, ddH, ..., eeH, sum
Byte Explanation
F0H Exclusive Status
41H Manufacturer ID (Roland)
10H Device ID
00H 1st byte of model ID (V-1SDI)
00H 2nd byte of model ID (V-1SDI)
00H 3rd byte of model ID (V-1SDI)
31H 4th byte of model ID (V-1SDI)
12H Command ID (DT1)
aaH Address upper byte
bbH Address middle byte
ccH Address lower byte
ddH Data: actual data to transmit. Multiple byte data is sent in address order.
: :
eeH Data
sum Checksum
F7H EOX (end of exclusive)
* Depending on the data type, the amount of single-time transmission is specied.
It is necessary to execute data request according to the specied rst address and
size. Refer to the “3. Parameter Address Map” (p. 14) for address and size.
* See “Example of an Exclusive Message and Calculating a Checksum” (p. 23) for
checksum.
* Data exceeding 256 bytes should be divided into packets of 256 bytes or smaller. If
you send data set 1 successively, set interval of 20 ms or longer between packets.

Roland V-1SDI Specifications

General

Interface	USB
Control type	Button, Jog dial, T-bar fader
Product color	Black
Built-in display	No
Built-in keyboard	Yes

Weight and Dimensions

Depth	108 mm
Width	313 mm
Height	59 mm
Weight	1200 g
