Roland V-1SDI Reference Manual

MIDI Implementation
13
2. MIDI Messages Transmitted from
MIDI OUT
Channel Voice Messages
z Control Change
{ Bank Select (Controller Number 0, 32)
Status 2nd Byte 3rd Byte
BnH 00H mmH
BnH 20H llH
mm, ll= Bank Number: 00 00H, 01 00H (bank.1, bank.2)
* When a video input or memory number has been selected, this transmits a bank
number along with a program change. Control for bank selects and program
changes is as follows.
MSB LSB Program No. Control
00H 00H 00H–03H A ch. INPUT 1–4
01H 00H 00H–03H B ch. INPUT 1–4
50H 00H 00H–07H MEMORY 1–8
{ Panpot (Controller Number 10)
Status 2nd Byte 3rd Byte
BnH 0AH vvH
* This transmits the value when the AUDIO MIXER’s SDI 1 audio input level has been
changed.
{ Expression (Controller Number 11)
Status 2nd Byte 3rd Byte
BnH 0BH vvH
* This transmits the value when the AUDIO MIXER’s SDI 2 audio input level has been
changed.
{ Eect Control 1 (Controller Number 12)
Status 2nd Byte 3rd Byte
BnH 0CH vvH
* This transmits the value when the AUDIO MIXER’s SDI 3 audio input level has been
changed.
{ Eect Control 2 (Controller Number 13)
Status 2nd Byte 3rd Byte
BnH 0DH vvH
* This transmits the value when the AUDIO MIXER’s HDMI 3 audio input level has
been changed.
{ Undened (Controller Number 14)
Status 2nd Byte 3rd Byte
BnH 0EH vvH
* This transmits the value when the AUDIO MIXER’s HDMI 4 audio input level has
been changed
{ Undened (Controller Number 15)
Status 2nd Byte 3rd Byte
BnH 0FH vvH
* This transmits the value when the AUDIO MIXER’s AUDIO IN audio input level has
been changed.
{ General Purpose Controllers 1 (Controller Number 16)
Status 2nd Byte 3rd Byte
BnH 10H vvH
* This transmits the value when the AUDIO MIXER’s MIC audio input level has been
changed.
{ General Purpose Controllers 2 (Controller Number 17)
Status 2nd Byte 3rd Byte
BnH 11H vvH
* This transmits the value when the AUDIO MIXER’s MASTER audio output level has
been changed.
{ General Purpose Controllers 3 (Controller Number 18)
Status 2nd Byte 3rd Byte
BnH 12H vvH
* This transmits the value when the A/B fader has been controlled.
{ General Purpose Controllers 4 (Controller Number 19)
Status 2nd Byte 3rd Byte
BnH 13H ttH
tt= TRANSITION TIME: 00H–28H (0.0–4.0 sec)
* This transmits the value when TRANSITION TIME has been changed.
{ Undened (Controller Number 20)
Status 2nd Byte 3rd Byte
BnH 14H ttH
tt= Transition Select: 00H–02H (WIPE, MIX, CUT)
* This transmits the value when the [WIPE], [MIX], or [CUT] button has been operated.
{ Undened (Controller Number 21)
Status 2nd Byte 3rd Byte
BnH 15H xxH
* This transmits the value when [DSK] button has been operated.
{ Undened (Controller Number 22)
Status 2nd Byte 3rd Byte
BnH 16H vvH
* This transmits the value when the [AUTO] button has been operated.
{ Undened (Controller Number 23)
Status 2nd Byte 3rd Byte
BnH 17H xxH
* This transmits the value when the [KEY LEVEL] button has been operated.
{ Undened (Controller Number 24)
Status 2nd Byte 3rd Byte
BnH 18H xxH
* This transmits the value when the [PinP] button has been operated.
{ Undened (Controller Number 25)
Status 2nd Byte 3rd Byte
BnH 19H xxH
* This transmits the value when the [SPLIT] button has been operated.
{ Undened (Controller Number 26)
Status 2nd Byte 3rd Byte
BnH 1AH vvH
* This transmits the value when the [OUTPUT FADE] knob has been operated.
{ Undened (Controller Number 27)
Status 2nd Byte 3rd Byte
BnH 1BH xxH
* This transmits the value when the [FREEZE] button has been operated.
