Roland V-1SDI Reference Manual

MIDI Implementation
21
z Other Parameter Area
{ MEMORY
Address Parameter Name Sys.Ex.Value Meaning of Value
73H 01H 00H MEMORY SELECT 00H–07H MEMORY 1–8
MEMORY SAVE 10H–17H MEMORY 1–8
MEMORY INIT 20H–28H This returns MEMORY 1–8 (20H–27H) and Current (28H) to default values.
* Sending 1nH or 2nH changes the memory selection to the specied memory.
* Even if 1nH or 2nH is specied, RQ1 results in sending of 00H–07H (the currently selected memory).
{ LED
Address Parameter Name Sys.Ex.Value Meaning of Value
73H 02H 00H LED OUTFADER BLACK 00H–01H OFF, GREEN (Read Only)
73H 02H 01H LED OUTFADER WHITE 00H–01H OFF, GREEN (Read Only)
73H 02H 02H LED FREEZE 00H–01H OFF, RED (Read Only)
73H 02H 03H LED MEMORY 00H–01H OFF, BLUE (Read Only)
73H 02H 04H LED AUDIO 00H–03H OFF, RED, GREEN, YELLOW (Read Only)
73H 02H 05H LED PEKSIG 00H–03H OFF, RED, GREEN, YELLOW (Read Only)
73H 02H 06H LED SETUP 00H–01H OFF, GREEN (Read Only)
73H 02H 07H LED PANELLOCK 00H–01H OFF, RED (Read Only)
73H 02H 08H LED PINP 00H–01H OFF, GREEN (Read Only)
73H 02H 09H LED SPLIT 00H–01H OFF, GREEN (Read Only)
73H 02H 0AH LED HDCP 00H–01H OFF, RED (Read Only)
73H 02H 0BH LED KEYLEVEL 00H–01H OFF, RED (Read Only)
73H 02H 0CH LED WIPE 00H–01H OFF, GREEN (Read Only)
73H 02H 0DH LED MIX 00H–01H OFF, GREEN (Read Only)
73H 02H 0EH LED CUT 00H–01H OFF, GREEN (Read Only)
73H 02H 0FH LED DSK 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 10H LED AUTO 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 11H LED VDOSEL1A 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 12H LED VDOSEL2A 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 13H LED VDOSEL3A 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 14H LED VDOSEL4A 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 15H LED VDOSEL1B 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 16H LED VDOSEL2B 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 17H LED VDOSEL3B 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
73H 02H 18H LED VDOSEL4B 00H–07H OFF, RED, GREEN, YELLOW, BLUE, MAZENTA, CYAN, WHITE (Read Only)
{ AUDIO LEVEL METER
Address Parameter Name Sys.Ex.Value Meaning of Value
73H 03H 00H AUDIO LEVEL METER MASTER L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 01H AUDIO LEVEL METER MASTER R 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 02H AUDIO LEVEL METER SDI1 L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 03H AUDIO LEVEL METER SDI1 R 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 04H AUDIO LEVEL METER SDI2 L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 05H AUDIO LEVEL METER SDI2 R 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 06H AUDIO LEVEL METER SDI3 L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 07H AUDIO LEVEL METER SDI3 R 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 08H AUDIO LEVEL METER HDMI3 L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 09H AUDIO LEVEL METER HDMI3 R 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 0AH AUDIO LEVEL METER HDMI4 L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 0BH AUDIO LEVEL METER HDMI4 R 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 0CH AUDIO LEVEL METER LINE L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 0DH AUDIO LEVEL METER LINE R 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 0EH AUDIO LEVEL METER MIC L 00H–33H -INF, -50–0 dB (Read Only)
73H 03H 0FH AUDIO LEVEL METER MIC R 00H–33H -INF, -50–0 dB (Read Only)

Roland V-1SDI Specifications

General

Interface	USB
Control type	Button, Jog dial, T-bar fader
Product color	Black
Built-in display	No
Built-in keyboard	Yes

Weight and Dimensions

Depth	108 mm
Width	313 mm
Height	59 mm
Weight	1200 g
