Roland V-1SDI Reference Manual

MIDI Implementation
20
{ Panel Parameter
Address Parameter Name Sys.Ex.Value Meaning of Value
#71H 03H 00H
01H
A/B FADER 00H 00H–07H 7F 0–1023
#71H 03H 02H
03H
CONTROL 1 VOL 00H 00H–01H 7FH 0–255
#71H 03H 04H
05H
CONTROL 2 VOL 00H 00H–01H 7FH 0–255
#71H 03H 06H
07H
OUTPUT FADER 00H 00H–01H 7FH 0–255
71H 03H 08H VIDEO SEL A 00H–03H Input 1–4
71H 03H 09H VIDEO SEL B 00H–03H Input 1–4
71H 03H 0AH [PinP] 00H–01H [PinP] button OFF, ON
71H 03H 0BH [SPLIT] 00H–01H [SPLIT] button OFF, ON
71H 03H 0CH TRANSITION PATTERN 00H–02H WIPE, MIX, CUT
71H 03H 0DH [DSK] 00H–01H [DSK] button OFF, ON
71H 03H 0EH [KEY LEVEL] 00H–01H [KEY LEVEL] button OFF, ON
71H 03H 0FH A/B FADER START POSITION 00H–01H 00H: bus A end, 01H: bus B end
#71H 03H 10H
11H
PinP 1/4 CONTROL 1 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 12H
13H
PinP 1/4 CONTROL 2 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 14H
15H
PinP 1/2 CONTROL 1 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 16H
17H
PinP 1/2 CONTROL 2 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 18H
19H
SPLIT VC CONTROL 1 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 1AH
1BH
SPLIT VC CONTROL 2 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 1CH
1DH
SPLIT HC CONTROL 1 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 1EH
1FH
SPLIT HC CONTROL 2 VOL
(PinP SW)
00H 00H–01H 7FH 0–255
#71H 03H 20H
21H
PinP 1/4 CONTROL 1 VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255
#71H 03H 22H
23H
PinP 1/4 CONTROL 2 VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255
#71H 03H 24H
25H
PinP 1/2 CONTROL 1 VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255
#71H 03H 26H
27H
PinP 1/2 CONTROL 2 VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255
#71H 03H 28H
29H
SPLIT VC CONTROL 1 VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255
#71H 03H 2AH
2BH
SPLIT VC CONTROL 2VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255
#71H 03H 2CH
2DH
SPLIT HC CONTROL 1 VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255
#71H 03H 2EH
2FH
SPLIT HC CONTROL 2 VOL
(SPLIT SW)
00H 00H–01H 7FH 0–255

Roland V-1SDI Specifications

General

Interface	USB
Control type	Button, Jog dial, T-bar fader
Product color	Black
Built-in display	No
Built-in keyboard	Yes

Weight and Dimensions

Depth	108 mm
Width	313 mm
Height	59 mm
Weight	1200 g
