Roland V-1SDI Reference Manual

MIDI Implementation
19
{ Audio Parameter-2
Address Parameter Name Sys.Ex.Value Meaning of Value
71H 02H 00H AUDIO IN EQ Hi 00H–1EH -15–15 dB
71H 02H 01H AUDIO IN EQ Hi FREQ 44H–78H 1.00–20.0 kHz
71H 02H 02H AUDIO IN EQ Mid 00H–1EH -15–15 dB
71H 02H 03H AUDIO IN EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 02H 04H AUDIO IN EQ Mid Q 00H–05H 0.5–16.0
71H 02H 05H AUDIO IN EQ Lo 00H–1EH -15–15 dB
71H 02H 06H AUDIO IN EQ Lo FREQ 00H–38H 20–500 Hz
71H 02H 07H Reserved
71H 02H 08H MIC IN EQ Hi 00H–1EH -15–15 dB
71H 02H 09H MIC IN EQ Hi FREQ 44H–78H 1.00–20.0 kHz
71H 02H 0AH MIC IN EQ Mid 00H–1EH -15–15 dB
71H 02H 0BH MIC IN EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 02H 0CH MIC IN EQ Mid Q 00H–05H 0.5–16.0
71H 02H 0DH MIC IN EQ Lo 00H–1EH -15–15 dB
71H 02H 0EH MIC IN EQ Lo FREQ 00H–38H 20–500 Hz
71H 02H 0FH MIC IN HPF 00H–01H OFF, ON
71H 02H 10H MIC IN COMP 00H–01H OFF, ON
71H 02H 11H MIC IN COMP THRESHOLD 00H–32H -50–0 dB
71H 02H 12H MIC IN COMP RATIO 00H–08H 1.0:1 – INF:1
71H 02H 13H MIC IN COMP ATTACK 00H–19H 0.2–100 ms
71H 02H 14H MIC IN COMP RELEASE 00H–7FH 30–5000 ms
71H 02H 15H MIC IN GATE 00H–01H OFF, ON
71H 02H 16H MIC IN GATE THRESHOLD 00H–32H -50–0 dB
71H 02H 17H MIC IN GATE RELEASE 00H–7FH 30–5000 ms
71H 02H 18H MASTER OUT EQ Hi 00H–1EH -15–15 dB
71H 02H 19H MASTER OUT EQ Hi FREQ 44H–78H 1.00–20.0 kHz
71H 02H 1AH MASTER OUT EQ Mid 00H–1EH -15–15 dB
71H 02H 1BH MASTER OUT EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 02H 1CH MASTER OUT EQ Mid Q 00H–05H 0.5–16.0
71H 02H 1DH MASTER OUT EQ Lo 00H–1EH -15–15 dB
71H 02H 1EH MASTER OUT EQ Lo FREQ 00H–38H 20–500 Hz
71H 02H 1FH Reserved
71H 02H 20H REVERB LEVEL 00H–7FH 0–127
71H 02H 21H REVERB TIME 00H–32H 0.0–5.0 sec
71H 02H 22H REVERB TYPE 00H–01H ROOM, HALL
71H 02H 23H REVERB SEND LEVEL SDI1 00H–7FH 0–127
71H 02H 24H REVERB SEND LEVEL SDI2 00H–7FH 0–127
71H 02H 25H REVERB SEND LEVEL SDI3 00H–7FH 0–127
71H 02H 26H REVERB SEND LEVEL HDMI3 00H–7FH 0–127
71H 02H 27H REVERB SEND LEVEL HDMI4 00H–7FH 0–127
71H 02H 28H REVERB SEND LEVEL AUDIO IN 00H–7FH 0–127
71H 02H 29H REVERB SEND LEVEL MIC IN 00H–7FH 0–127
71H 02H 2AH MASTERING 00H–01H OFF, ON
71H 02H 2BH MASTERING NOISE SUPPRESSOR 00H–7FH 0–127
71H 02H 2CH MASTERING ENHANSER 00H–7FH 0–127
71H 02H 2DH MASTERING Hi 00H–7FH 0–127
71H 02H 2EH MASTERING Mid 00H–7FH 0–127
71H 02H 2FH MASTERING Lo 00H–7FH 0–127
