Roland V-1SDI Reference Manual

MIDI Implementation
18
Address Parameter Name Sys.Ex.Value Meaning of Value
#71H 01H 12H
13H
DELAY SDI2 00H 00H–27H 08H 0.0–500.0 ms
#71H 01H 14H
15H
DELAY SDI3 00H 00H–27H 08H 0.0–500.0 ms
#71H 01H 16H
17H
DELAY HDMI3 00H 00H–27H 08H 0.0–500.0 ms
#71H 01H 18H
19H
DELAY HDMI4 00H 00H–27H 08H 0.0–500.0 ms
#71H 01H 1AH
1BH
DELAY AUDIO IN 00H 00H–27H 08H 0.0–500.0 ms
#71H 01H 1CH
1DH
DELAY MIC IN 00H 00H–27H 08H 0.0–500.0 ms
71H 01H 1EH Reserved
71H 01H 1FH Reserved
71H 01H 20H SDI1 IN EQ Hi 00H–1EH -15–15 dB
71H 01H 21H SDI1 IN EQ Hi FREQ 44H–78H 1.00–20.0 kHz
71H 01H 22H SDI1 IN EQ Mid 00H–1EH -15–15 dB
71H 01H 23H SDI1 IN EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 01H 24H SDI1 IN EQ Mid Q 00H–05H 0.5–16.0
71H 01H 25H SDI1 IN EQ Lo 00H–1EH -15–15 dB
71H 01H 26H SDI1 IN EQ Lo FREQ 00H–38H 20–500 Hz
71H 01H 27H Reserved
71H 01H 28H SDI2 IN EQ Hi 00H–1EH -15–15 dB
71H 01H 29H SDI2 IN EQ Hi FREQ 44H–78H 1.00–20.0 kHz
71H 01H 2AH SDI2 IN EQ Mid 00H–1EH -15–15 dB
71H 01H 2BH SDI2 IN EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 01H 2CH SDI2 IN EQ Mid Q 00H–05H 0.5–16.0
71H 01H 2DH SDI2 IN EQ Lo 00H–1EH -15–15 dB
71H 01H 2EH SDI2 IN EQ Lo FREQ 00H–38H 20–500 Hz
71H 01H 2FH Reserved
71H 01H 30H SDI3 IN EQ Hi 00H–1EH -15–15 dB
71H 01H 31H SDI3 IN EQ Hi FREQ 44H–78H 1.00–20.0 kHz
71H 01H 32H SDI3 IN EQ Mid 00H–1EH -15–15 dB
71H 01H 33H SDI3 IN EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 01H 34H SDI3 IN EQ Mid Q 00H–05H 0.5–16.0
71H 01H 35H SDI3 IN EQ Lo 00H–1EH -15–15 dB
71H 01H 36H SDI3 IN EQ Lo FREQ 00H–38H 20–500 Hz
71H 01H 37H Reserved
71H 01H 38H HDMI3 IN EQ Hi 00H–1EH -15–15 dB
71H 01H 39H HDMI3 IN EQ Hi FREQ 44H–78H 1.00–20.0 kH
71H 01H 3AH HDMI3 IN EQ Mid 00H–1EH -15–15 dB
71H 01H 3BH HDMI3 IN EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 01H 3CH HDMI3 IN EQ Mid Q 00H–05H 0.5–16.0
71H 01H 3DH HDMI3 IN EQ Lo 00H–1EH -15–15 dB
71H 01H 3EH HDMI3 IN EQ Lo FREQ 00H–38H 20–500 Hz
71H 01H 3FH Reserved
71H 01H 40H HDMI4 IN EQ Hi 00H–1EH -15–15 dB
71H 01H 41H HDMI4 IN EQ Hi FREQ 44H–78H 1.00–20.0 kHz
71H 01H 42H HDMI4 IN EQ Mid 00H–1EH -15–15 dB
71H 01H 43H HDMI4 IN EQ Mid FREQ 00H–78H 20 Hz–20.0 kHz
71H 01H 44H HDMI4 IN EQ Mid Q 00H–05H 0.5–16.0
71H 01H 45H HDMI4 IN EQ Lo 00H–1EH -15–15 dB
71H 01H 46H HDMI4 IN EQ Lo FREQ 00H–38H 20–500 Hz

Roland V-1SDI Specifications

General

Interface	USB
Control type	Button, Jog dial, T-bar fader
Product color	Black
Built-in display	No
Built-in keyboard	Yes

Weight and Dimensions

Depth	108 mm
Width	313 mm
Height	59 mm
Weight	1200 g
