Roland V-1SDI Reference Manual

MIDI Implementation
17
Address Parameter Name Sys.Ex.Value Meaning of Value
71H 00H 0CH CH4 HDMI EDID 00H–0EH
AUTO, 480/576i, 480/576p, 720p, 1080i, 1080p, 640x480, 800x600,
1024x768, 1280x768, 1280x1024, 1366x768, 1400x1050, 1600x1200,
1920x1200
71H 00H 0DH Reserved
71H 00H 0EH SDI PVW ASSIGN 00H–02H MULTI-VIEW, PST, PGM
71H 00H 0FH 3G-SDI MAPPING 00H–01H LEVEL A, LEVEL B
71H 00H 10H HDMI PVW ASSIGN 00H–02H MULTI-VIEW, PST, PGM
71H 00H 11H HDMI OUT COLOR SPACE 00H–03H AUTO, RGB 0-255, RGB 16-235, YCC
71H 00H 12H DVI-D/HDMI SIGNAL 00H–02H AUTO, DVI-D, HDMI
71H 00H 13H VIDEO OUT CONTRAST 00H–7FH -64–63
71H 00H 14H VIDEO OUT SATURATION 00H–7FH -64–63
71H 00H 15H VIDEO OUT BRIGHTNESS 00H–7FH -64–63
71H 00H 16H Reserved
71H 00H 17H TRANSITION TIME 00H–28H 0.0–4.0 sec
71H 00H 18H WIPE PATTERN 00H–1DH
H-DOWN, H-UP, V-RIGHT, V-LEFT, H-IN, H-OUT, V-IN, V-OUT, R-DOWN,
L-DOWN, R-UP, L-UP, BLOCK, V-GRID, H-GRID, H-DOWN/s, H-UP/s,
V-RIGHT/s, V-LEFT/s, H-IN/s, H-OUT/s, V-IN/s, V-OUT/s, -DOWN/s,
L-DOWN/s, R-UP/s, L-UP/s, BLOCK/s, V-GRID/s, H-GRID/s
71H 00H 19H MIX PATTERN 00H–03H MIX, FAM, NAM, MOSAIC
71H 00H 1AH PinP PATTERN 00H–06H PinP 1/4, PinP 1/2, SPLIT-VS, SPLIT-VC, SPLIT-HS, SPLIT-HC, QUAD
71H 00H 1BH SPLIT PATTERN 00H–06H PinP 1/4, PinP 1/2, SPLIT-VS, SPLIT-VC, SPLIT-HS, SPLIT-HC, QUAD
71H 00H 1CH PinP BORDER WIDTH 00H–0FH 0–15
71H 00H 1DH PinP BORDER COLOR 00H–06H BLACK, WHITE, GRAY, RED, GREEN, BLUE, YELLOW
71H 00H 1EH Reserved
71H 00H 1FH DSK ON/OFF 00H–01H OFF, ON
71H 00H 20H DSK SOURCE CH 00H–03H INPUT1, INPUT2, INPUT3, INPUT4
71H 00H 21H KEY TYPE 00H–03H WHT-L.KEY, BLK-L.KEY, GRN-C.KEY, BLU-C.KEY
#71H 00H 22H
23H
KEY LEVEL 00H 00H–01H 7FH 0–255
#71H 00H 24H
25H
KEY GAIN 00H 00H–01H 7FH 0–255
#71H 00H 26H
27H
MIX LEVEL 00H 00H–01H 7FH 0–255
#71H 00H 28H
29H
HUE WIDTH 00H 00H–01H 7FH -128–127
#71H 00H 2AH
2BH
HUE FINE 00H 00H–01H 7FH -128–127
#71H 00H 2CH
2DH
SATURATION WIDTH 00H 00H–01H 7FH -128–127
#71H 00H 2EH
2FH
SATURATION FINE 00H 00H–01H 7FH 0–255
{ Audio Parameter-1
Address Parameter Name Sys.Ex.Value Meaning of Value
71H 01H 00H SDI1 INPUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 01H SDI2 INPUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 02H SDI3 INPUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 03H HDMI3 INPUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 04H HDMI4 INPUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 05H AUDIO INPUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 06H MIC INPUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 07H MASTER OUT LEVEL 00H–7FH -INF–+6.0 dB
71H 01H 08H A. FOLLOW SDI1 00H–01H OFF, ON
71H 01H 09H A. FOLLOW SDI2 00H–01H OFF, ON
71H 01H 0AH A. FOLLOW SDI3 00H–01H OFF, ON
71H 01H 0BH A. FOLLOW HDMI3 00H–01H OFF, ON
71H 01H 0CH A. FOLLOW HDMI4 00H–01H OFF, ON
71H 01H 0DH A. FOLLOW AUDIO IN 00H–04H OFF, 1–4
71H 01H 0EH A. FOLLOW MIC IN 00H–04H OFF, 1–4
71H 01H 0FH Reserved
#71H 01H 10H
11H
DELAY SDI1 00H 00H–27H 08H 0.0–500.0 ms

Roland V-1SDI Specifications

General

Interface	USB
Control type	Button, Jog dial, T-bar fader
Product color	Black
Built-in display	No
Built-in keyboard	Yes

Weight and Dimensions

Depth	108 mm
Width	313 mm
Height	59 mm
Weight	1200 g
