Roland V-1SDI Reference Manual

MIDI Implementation
16
Address Parameter Name Sys.Ex.Value Meaning of Value
70H 01H 1EH FREEZE MODE 00H–01H ALL, SELECT
70H 01H 1FH DEINTERLACE MODE 00H–01H WEAVE, BOB
70H 01H 20H AUTO OFF 00H–01H OFF, ON
70H 01H 21H OUTPUT FADER ASSIGN 00H–03H VIDEO, V & A, AUDIO, BLACK / A
70H 01H 22H PVW INDICATER LABEL 00H–01H OFF, ON
70H 01H 23H PVW INDICATER TALLY 00H–01H OFF, ON
70H 01H 24H PVW INDICATER AUDIO 00H–02H OFF, UPPER, LOWER
70H 01H 25H AUTO SCAN ON/OFF 00H–01H OFF, ON
70H 01H 26H AUTO SCAN TIME 01H–78H 1–120 sec
70H 01H 27H AUTO SCAN TRANS TIME 00H–28H 0.0–4.0 sec
70H 01H 28H COLOR BAR OUTPUT 00H–01H OFF, ON
70H 01H 29H TEST TONE OUTPUT 00H–03H OFF, -20 dB@1 kHz, -6 dB@1 kHz, 0 dB@1 kHz
70H 01H 2AH RS-232 PANEL STATUS 00H–01H OFF, ON
z Video/Audio/Panel Parameter Area
{ Video, Audio, Panel Parameter Area
These modify current operation.
Address Parameter Name
71H 00H 00H Video
71H 01H 00H Audio Parameter-1
71H 02H 00H Audio Parameter-2
71H 03H 00H Panel Parameter
{ Video, Audio, Panel Parameter Memory Area
These read or overwrite data saved at memory numbers other than the one currently selected. Data saved at the currently selected memory is not modied.
* The parameters in “Video Parameter” (p. 16), “Audio Parameter-1” (p. 17), “Audio Parameter-2” (p. 18) and “Panel Parameter” (p. 20) are also common to the video,
audio and panel parameter memory area.
Address Parameter Name Address Parameter Name
72H 00H 00H Video (Memory 1) 72H 10H 00H Video (Memory 5)
72H 01H 00H Audio Parameter-1 (Memory 1) 72H 11H 00H Audio Parameter-1 (Memory 5)
72H 02H 00H Audio Parameter-2 (Memory 1) 72H 12H 00H Audio Parameter-2 (Memory 5)
72H 03H 00H Panel (Memory 1) 72H 13H 00H Panel (Memory 5)
72H 04H 00H Video (Memory 2) 72H 14H 00H Video (Memory 6)
72H 05H 00H Audio Parameter-1 (Memory 2) 72H 15H 00H Audio Parameter-1 (Memory 6)
72H 06H 00H Audio Parameter-2 (Memory 2) 72H 16H 00H Audio Parameter-2 (Memory 6)
72H 07H 00H Panel (Memory 2) 72H 17H 00H Panel (Memory 6)
72H 08H 00H Video (Memory 3) 72H 18H 00H Video (Memory 7)
72H 09H 00H Audio Parameter-1 (Memory 3) 72H 19H 00H Audio Parameter-1 (Memory 7)
72H 0AH 00H Audio Parameter-2 (Memory 3) 72H 1AH 00H Audio Parameter-2 (Memory 7)
72H 0BH 00H Panel (Memory 3) 72H 1BH 00H Panel (Memory 7)
72H 0CH 00H Video (Memory 4) 72H 1CH 00H Video (Memory 8)
72H 0DH 00H Audio Parameter-1 (Memory 4) 72H 1DH 00H Audio Parameter-1 (Memory 8)
72H 0EH 00H Audio Parameter-2 (Memory 4) 72H 1EH 00H Audio Parameter-2 (Memory 8)
72H 0FH 00H Panel (Memory 4) 72H 1FH 00H Panel (Memory 8)
{ Video Parameter
Address Parameter Name Sys.Ex.Value Meaning of Value
71H 00H 00H CH3 INPUT SELECT 00H–02H AUTO, SDI, HDMI
71H 00H 01H CH4 HDMI SCALING TYPE 00H–03H FULL, LETTERBOX, CROP, DOT BY DOT
#71H 00H 02H
03H
CH4 HDMI H. POSITION 00H 00H–1EH 00H
-1920–1920
* Only values that are multiples of 8 can be specied.
#71H 00H 04H
05H
CH4 HDMI V. POSITION 00H 00H–10H 70H
-1080–1080
* Only values that are multiples of 8 can be specied.
#71H 00H 06H
07H
CH4 HDMI ZOOM 00H 32H–01H 48H 50–200
71H 00H 08H CH4 HDMI CONTRAST 00H–7FH -64–63
71H 00H 09H CH4 HDMI SATURATION 00H–7FH -64–63
71H 00H 0AH CH4 HDMI BRIGHTNESS 00H–7FH -64–63
71H 00H 0BH CH4 HDMI FLICKER FILTER 00H–01H OFF, ON
