VA-7
July, 2000
9
J3629107 ELECTRL.COND. 1UF 100V P5 C116 on AB / C5, 13 on EQB3 3
J5369103 ELECTR. COND. RV2 100U 16V (SMD) C71, 203, 216, 219, 215 on MB 5
J5369104 ELECTR. COND. RV2 10U 16V (SMD) C2, 38 on MB 2
J5369105 ELECTR. COND. RV3 33U 16V (SMD) C1, 15, 17, 93, 96, 118, 147, 148, 175, 176, 202 on MB 11
J5369102 ELECTR.COND. RV2 47U 16V SMD C188, 201 on MB 2
J5369106 ELECTR. COND. RV2 1U 50V (SMD) C68 on MB 1
J3629149 ELECTR.COND. 100U 16V H.7 C17, 19 on PB 2
J3629143 ELECTR. COND. 10U 16V H.7 C44, 45 on DBM 2
J3629137 ELECTR. COND. 33U 16V H.7 C4, 8, 12 on PB / C21 on CB 4
J3629150 ELECTR.COND. 47U 16V H.7 C19 on CB 1
J3629142 ELECTR. COND. 1U 63V H.7 C8 on RB / C43 on DBM 2
13649103J0 UNPOL.COND. 10U 16 P5 C102, 105, 109, 113, 117, 118 on AB / C60, 75 on AMP.B 8
# 00239412 POLYEST.COND. AMZV0050J122 0200 C53, 61 on AB 2
# 00239390 POLYEST.COND. AMZV0050J561 0200 C64, 56 on AB 2
INDUCTOR, COIL, FILTER
<<EMI>> 22448240 NOISE SUP. BL02RN2-R62 L1=>6 on PHB 6
<<EMI>> 12449370 NOISE SUP. SBT-0160W L4, 7, 11, 12, 13 on AB / L5, 7, 9, 10, 11 on MIDI 10
<<EMI>> 12449326 NOISE SUP. SBT-0460 L6, 12 on MIDI / L4 on FC7 3
<<EMI>> 13529187 NOISE SUP. ELKTR391CA FL1 on PB / FL1=>7 on FC7 8
<<EMI>> J2399103 CHIP NOISE SUP. ELKS471FA FL2=>10 on MB 8
<<EMI>> J2399104 CHIP NOISE SUP. EXCCL4532U1 L2=>9, 18, 39, 40, 41, 42, 44, 51, 52, 53 on MB / L10 on AB 19
<<EMI>> 00452034 CHIP NOISE SUP. BK2125HM102 L21=>38, 43 on MB 19
<<EMI>> 00907856 NOISE SUP. BLM21A601SPT CHIP L3, 5, 6 on AB 3
<<EMI>> 12449449 INDUCTOR RCH-875-151K L1 on LCD 1
CRYSTAL, RESONATOR
00894023 X-TAL 20.000 MHZ MA-406 X1 on MB 1
00894034 X-TAL 16.000 MHZ MA-406 X2 on MB 1
RELAY
12439224RI RELAY DS2YS-12V RL1 on AMP.B / RL1 on AB 2
ENCODER
01013223 EVQ-VEM F01-24B ENCODER ENC1 on CB 1
CONNECTOR
13419677RI 16P FEM. CONNECTOR AMP 1.27 CN15, 16 on MB / CN3 on LB / CN4 on RB 4
13429325 7P FEMALE CONN. P.2.5 JST CN1 on EQB 1
J3429123 8P FEM. CONNECTOR IL-404-08S-LW CN1 on RB 1
01454112 12P CONN. 006216012100808 CN1 on LCD 1
# J3429125 FEMALE CONNECTOR 52043-0410 CN7 on LCD 1
13439479RI MALE CONN.AMP 6W STANDING CN6 on PB 1
13369550RI 40P MALE CONN. P. 1.27 CN22 on MB 1
13419676RI 8P MALE CONN. P/2.5 MOLEX CN2 on MIDI / CN6 on MB 2
13369688RI 4P MALE CONN. P 2.5 M CN1 on IB / CN1, 3 on AMP.B 3
J3439103 6P MALE CONNECTOR P 2.5 M CN2 on AMP.B / CN 1 on PHB / CN4 on AB 3
J3439106 9P MALE CONNECTOR P 2.5 M CN1 on MIDI / CN9, 10 on MB / CN9 on AB 4
J3439109 5P MALE CONNECTOR P 2.5 M CN8 on AB 1
J3439113 7P MALE CONNECTOR P 2.5 M CN10 on AB / CN4, 5 on AMP.B 3
J3439120 4P MALE CONN. P.2 M CN2 on RB / CN29 on MB / CN12 on AB / CN3 on PB 4
J3439122 8P MALE CONNECTOR P.2 M CN2 on FC7 / CN3 on AB / CN7 on MB 3
J3439125 5P MALE CONNECTOR P.2 M CN26 on MB 1
J3439151 9P MALE CONNECTOR P.2 M CN11 on AB 1
J3439141 10P MALE CONNECTOR P.2 M CN1 on MB 1
J3439143 34P MALE CONN. P. 1.27 M CN17 on MB 1
J3439124 10P MALE CONN. P. 2 M 90° CN8 on CB 1
J3439126 12P MALE CONN. P.2 M CN1 on MB / CN1 on CVP 2
J3439146 11P MALE CONNECTOR P.2 M CN3, 25 on MB / CN2 on CVP 3
J3439147 14P MALE CONNECTOR P.2 M CN8 on MB / CN5 on AB 2
J3429120 3P MALE CONNECTOR P.2 M CN13 on AB/CN5 on LCD/CN2, 27 on MB/CN4 on CVP/CN401 on AFT 6
J3439148 7P MALE CONNECTOR P.2 M CN3 on CVP / CN21 on MB 3
13369592 7P MALE CONNECTOR P.2.5 JST CN6 on LCD 1
J3439159 4P MALE CONN. 53254 90° P.2 CN2 on PB 1
J3439162 13P MALE CONN. P.2 M CN23 on MB / CN2 on LCD 2
J3439168 4P MALE CONNECTOR 76384-404 CN402 on AFT 1
13369568 B3B-PH-K-S CONNECTOR CN4 on LCD / CN3 on FC7 2
13369503 B7B-PH-K-S CONNECTOR CN6 on LCD / CN24 on MB 2
01349645 2P MALE CONNECTOR S2(4-2.3)B-XH-A CN2 on IB 1
J3439171 4P MALE CONNECTOR 90° P.2 M CN6, 11 on CB / CN5 on PB / CN1 on CDBM 4
# 02230034 KX14-40K5D CONNECTOR CN11 on MB 1
# J3439172 8P MALE CONNECTOR 90°P.2 M CN10 on CB 1
# J3439173 7P MALE CONNECTOR 90°P.2 M CN17 on CB 1
# J3439174 9P MALE CONNECTOR 90°P.2 M CN4 on PB 1
# J3439175 11P MALE CONNECTOR 90° P.2 M CN1 on PB / CN16 on CB 2
# J3439176 12P MALE CONNECTOR 90°P.2 M CN7, 15 on CB 2
WIRING, CABLE
00783234 BENDER CABLE (35) (W4PC P.2) For details refer to WIRING DIAGRAM on page 6. 1
K3468155 4P CABLE 2R/2N (28) 2C D/R 1
# K3468217 4P CABLE (72/96) -1C 4PC 1
# K3468218 4P CABLE (72) -2C D/D 1
# K2468106 7P CABLE (12) -2C D/R 1
# K3468219 7P CABLE (32) -2C D/R 1
K3468171 9P CABLE (22) -2C D/R 1
K3468198 34P FLAT CABLE (18) -2C 1
J3469143 1P CONN. AWG18 (10) - YELLOW 2
7697212001 6P CABLE (64) -2C 1
7697220001 8P CABLE (32) -2C 1
7695108001 16P FLAT CABLE (24) -2C 1
7697223001 16P FLAT CABLE (38) -2C 1
# K3468220 40P FLAT CABLE CM.18 -2C D/D 1
# 7770116000 WIRING ASSY (W/5 CABLE ASSY) 1
# 7770118000 WIRING ASSY (W/4 CABLE ASSY) 1
# 7770117000 WIRING ASSY (W/5 CABLE ASSY) 1
# 7770119000 WIRING ASSY (W/3 CABLE ASSY) 1
# 7770120000 WIRING ASSY (W/4 CABLE ASSY) 1
7698907000 4P CABLE ASSY (6) -2C P.2 1
7699415000 3P CABLE ASSY (44) -2C P.2 1
# 7770121000 3P CABLE ASSY 2V/1R (38) -2C 4P D/R 1
# 7770122000 4P CABLE ASSY (32) 2C P.2 D/R 1
# 7770123000 5P CABLE ASSY (12) -2C P.2 D/R 1
# 7770124000 3P CABLE ASSY 2N/1R (54) -2C 4P D/D 1
7700424000 11P CABLE ASSY (12) -2C P.2 1
SCREW
J2289102 SELF TAP.SCREW .9X10 TC TC 4
J2289202 SELF TAP.SCREW 2.9X16 C C 3
J2289116 SELF TAP.SCREW 3.5X13 TC TC 4
J2289213 SELF TAP.SCREW 3.9X16 TC TC 2
J2289126 SELF TAP.SCREW 2.9X 8 TCTCPRBZ 4
J2289125 SCREW 2.9X10 TC TC PR TROP 121
J2289130 SCREW 2.9X13 TC TC PR TROP 4
J2289131 SELF TAP.SCREW 3.5X16 TCTCPRBZ 5
J2289108 SELF LOCK.SCREW M3X10 TCTC H.6 12
J2289147 SELF LOCK.SCREW M3X12 TCTC H.6 2
J2289193 SELF LOCK.SCREW M3X6 TC TC H.6 36
# J2289230 NYLON SCREW M3X12 G030MA012 1
J2289149 SCREW 3X20 TC TFR H.7 4
J2289186 SCREW 3.5X16 TCPR TFR H.8 BRUN 71
PACKING
# K2638234 RIGHT POLYSTH. END SIDE VA-7 1
# K2638235 LEFT POLYSTH. END SIDE VA-7 1
# K2638236 CENTRAL LDPE PROTECTION VA-7 1
K2678119 CARTENE ENVELOPE HD CM.170X56 1
K2678102 POLYETH. ENVELOPE 5X45 1
K2678106 POLYETH.ENVELOPE 4OX55 1
# K2618229 OUTER PACKING VA-7 1
MISCELLANEOUS
# K2148114 HEXAGONAL ROD M3 6X14 8
J2289113 NUT 3MA H.3 2
J2139111 FLAT WASHER I/D 3X7 TH. 0.6 4
J2139102 TOOTHED WASHER I/D 3 2
22165134 BRASS BUSHING 8
K2168114 LED SPACER H.1.8 E.D.9 18
00453223 LED SPACER H. 7 E.D. 5 2
# K2168117 LED SPACER H.1.5 D.E.5.5 59
K216810801 SPACER F/LED H. 5.5 - E/D 5.5 5
J2359101 SPACER 3M ART. SJ5012 5
22265242 RUBBER GUIDE BUSHING 8
J2159102 PLASTIC RIVET SR3055 2
K2228103 SPEAKER GASKET 108/88 TH.2 2
K2248150 FELT WASHER I/D 7 E/D 13 TH.1.5 3
# K2248152 BLACK ANTIDUST COVER PL45N LCD 1
# K2268164 RIGHT VIBRATION DAMPER PL45N 1
# K2268165 LEFT VIBRATION DAMPER PL45N 1
# K2268166 VIBRATION DAMPER F/VARIPH. CONTROL B. 1
12199584 FIXING SUPPORT M1698 2
01121790 RIBBON SENSOR 1
K2198105 SENSOR SUPPORT EM-20 1
K2248127 PROTECTING BOX COVER F/INVERTER 1
K2248128 PROTECTING BOX BASE F/INVERTER 1
K1188130 TWEETER SUPPORT EM2000/EG101 2
01343089 D-BEAM CONTROLLER ESCT BLK 1
# K2238127 DIFFUSER FOR LED 10
K253810302 FUSE WARNING LABEL 1
ACCESSORIES
# 7770131000 ZIP DISK DEMO/STYLE/SONG/SAMPLE VA-7 1
# 7770136000 ZIP DISK DEMO/STYLE/SAMPLE VA-7 (only for US market) 1
K6018109 MIDI GUIDE 1
# K6018390 OWNER'S MANUAL (E) VA-7 1
# K6018391 MIDI IMPLEMENTATION MANUAL VA-7 1
# K6018396 OWNER'S MANUAL (D) VA-7 1
# K6018397 OWNER'S MANUAL (F) VA-7 1
# 7770133000 SYSTEM UPDATE DISK VA-7 1
# 7770134000 TEST UPDATE DISK VA-7 1
# 7770135000 VARIPHRASE UPDATE ZIP DISK VA-7 1
J3439150 MAINS CABLE H05VV+POL.. SOCKET (230V) 1
J3439128 CABLE 498/3 SJT 2X18 AWG-C17 (117V) 1
13499152RI CABLE BS/13/H05VV-F3G0 75-V (230VE) 1
J3439167 MAINS CABLE SAA/2-H05VV5 2X1-C17 (240VA) 1
