Roland VC-1 Series User Manual

SDI to HDMI
Conversion of video and audio signals from SDI input to HDMI output
VC-1-SH
HDMI to SDI
Conversion of video and audio signals from HDMI input to SDI output
VC-1-HS
●
●
●
●
●
SDI
Input
SDI
Output
USB
Port
Audio
Input
HDMI
Output
Audio
Output
DC IN
Connector
SDI
Output 1
SDI
Output 2
USB
Port
Audio
Output
HDMI
Output
HDMI
Input
Audio
Input
DC IN
Connector
●
●
●
●
●
SDI to HDMI Conversion
Lossless image conversion
3G
(
Level A&B
)
/ HD / SD SDI
HDCP support
Selectable Channel for
Embedded / De-Embedded Audio
HDMI to SDI Conversion
Lossless image conversion
3G
(
Level A&B
)
/ HD / SD SDI
HDCP support
Selectable Channel for
Embedded / De-Embedded Audio
Block Diagram
SDI IN
SDI
THRU/OUT
Analog/AES3
L
−
AUDIO IN
−
R
Analog/AES3
L
−
AUDIO OUT
−
R
Audio
Embedded
Audio
De-Embedded
HDMI OUT
Block Diagram
HDMI IN
HDMI
THRU/OUT
Analog/AES3
L
−
AUDIO IN
−
R
Analog/AES3
L
−
AUDIO OUT
−
R
Audio
Embedded
Audio
De-Embedded
SDI OUT 1
SDI OUT 2
MODE DIP SW
MODE DIP SW
*Up/Down/Cross, Frame rate, I/P, and Aspect ratio conversion
are not supported.
*Up/Down/Cross, Frame rate, I/P, and Aspect ratio conversion
are not supported.
