Appendices
MIDI Implementation
Model: XP-30 (64 Voice Expandable Synthesizer)
Version: 1.00
Date: Jan. 18 1999
1. Data Reception (sound source section)
■ Channel Voice Messages
● Note Off
status 2nd byte 3rd byte
8nH kkH vvH
9nH kkH 00H
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=note number: 00H - 7FH (0 - 127)
vv=Note Off velocity: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Rx parameter (PERFORM/MIDI/MIDI) is
OFF.
* Not received by the Rhythm Part (Part 10) when the Env Mode parameter (RHYTHM/
CONTROL/CONTROL) is NO-SUS.
● Note On
status 2nd byte 3rd byte
9nH kkH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=note number: 00H - 7FH (0 - 127)
vv=Note On velocity: 01H - 7FH (1 - 127)
* Not received in Performance mode when the Rx parameter (PERFORM/MIDI/MIDI) is
OFF.
● Polyphonic Aftertouch
status 2nd byte 3rd byte
AnH kkH vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
kk=note number: 00H - 7FH (0 - 127)
vv=Aftertouch: 00H - 7FH (0 - 127)
* This message is received if the Aftertouch parameter (SYSTEM/CONTROL/CONTROL
SOURCE) is POLY or CH&POLY.
* Not received in Performance mode when the Rx parameter (PERFORM/MIDI/MIDI) is
OFF.
* Not received in GM mode.
● Control Change
* If the corresponding Controller number is selected for the Control 2 or Control 3
parameter (PATCH/CONTROL/CONTROL SOURCE), the corresponding effect will
occur.
* If a Controller number that corresponds to the Control 1 parameter or Control 2
parameter (SYSTEM/CONTROL/SYS-CTRL ASSIGN) is selected, the specified effect
will apply if Control 2 parameter or Control 3 parameter (PATCH/CONTROL/
CONTROL SOURCE) is set to SYS-CTRL1 or SYS-CTRL2.
* Not received in Performance mode when the Rx parameter (PERFORM/MIDI/MIDI) or
the Control Change Receive Switch is OFF.
❍Bank Select (Controller number 0,32)
status 2nd byte 3rd byte
BnH 00H mmH
BnH 20H llH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
mm,ll=Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)
* Not received when the Program Change parameter or Bank Select parameter (SYSTEM/
MIDI/RECEIVE MIDI) is OFF.
* Not received in GM mode.
* The Patches corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Patch No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
80 | 0 | 0 - 127 | User 1 - 128
81 | 0 | 0 - 127 | PR-A 1 - 128
81 | 1 | 0 - 127 | PR-B 1 - 128
81 | 2 | 0 - 127 | PR-C 1 - 128
81 | 3 | 0 - 127 | GM 1 - 128
81 | 4 | 0 - 127 | PR-E 1 - 128
84 | 0 | 0 - 127 | XP-A (Session) 1 - 128
84 | 1 | 0 - 126 | XP-A 129 - 255
84 | 2 | 0 - 127 | XP-B (Orchestral) 1 - 128
84 | 3 | 0 - 126 | XP-B 129 - 255
84 | 4 | 0 - 127 | XP-C (Techno Collection) 1 - 128
84 | 5 | 0 - 127 | XP-C 129 - 256
84 | 6 | 0 - 127 | XP-D 1 - 128
84 | 7 | 0 - 127 | XP-D 129 - 256
84 | 8 | 0 - 127 | XP-E 1 - 128
84 | 9 | 0 - 127 | XP-E 129 - 256
* The Performance corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Performance No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
80 | 0 | 0 - 31 | User 1 - 32
81 | 0 | 0 - 31 | PR-A 1 - 32
81 | 1 | 0 - 31 | PR-B 1 - 32
* The Rhythm set corresponding to each Bank Select are as follows.
Bank Select | Program No | Group Rhythm set No.
MSB | LSB | |
——————+—————+————————————+————————————————————————————————————————
80 | 0 | 0 - 1 | User 1 - 2
81 | 0 | 0 - 1 | PR-A 1 - 2
81 | 1 | 0 - 1 | PR-B 1 - 2
81 | 2 | 0 - 1 | PR-C 1 - 2
81 | 3 | 0 - 1 | GM 1 - 2
81 | 4 | 0 - 1 | PR-E 1 - 2
84 | 0 | 0 - 7 | XP-A (Session) 1 - 8
84 | 4 | 0 - 7 | XP-C (Techno Collection) 1 - 8
84 | 6 | 0 - 127 | XP-D 1 - 128
84 | 7 | 0 - 127 | XP-D 129 - 256
84 | 8 | 0 - 127 | XP-E 1 - 128
84 | 9 | 0 - 127 | XP-E 129 - 256
❍Modulation (Controller number 1)
status 2nd byte 3rd byte
BnH 01H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Modulation depth: 00H - 7FH (0 - 127)
❍Breath Type (Controller number 2)
status 2nd byte 3rd byte
BnH 02H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127)
❍Foot Type (Controller number 4)
status 2nd byte 3rd byte
BnH 04H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=control value: 00H - 7FH (0 - 127)
❍Portamento Time (Controller number 5)
status 2nd byte 3rd byte
BnH 05H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Portamento Time: 00H - 7FH (0 - 127)
* The Time parameter (PATCH/CONTROL/PORTAMENTO) will change.
❍Data Entry (Controller number 6, 38)
status 2nd byte 3rd byte
BnH 06H mmH
BnH 26H llH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
mm,ll= the value of the parameter specified by RPN/NRPN
mm=MSB, ll=LSB
❍Volume (Controller number 7)
status 2nd byte 3rd byte
BnH 07H vvH
n=MIDI channel number: 0H - FH (ch.1 - ch.16)
vv=Volume: 00H - 7FH (0 - 127)
