Chapter 12. Realizing the Potential of the XV-88
Chapter 12
Selecting Patches
The MIDI messages transmitted by the external MIDI device
will be received by the XV-88 to select Patches as shown in
the following table.
Group Number Bank Select Program Change
MSB LSB Number
USER 001–128 87 00 001–128
CD-A 001–128 87 32 001–128
:::::
CD-H 001–128 87 39 001–128
PR-A 001–128 87 64 001–128
PR-B 001–128 87 65 001–128
PR-C 001–128 87 66 001–128
PR-D 001–128 87 67 001–128
PR-E 001–128 87 68 001–128
PR-F 001–128 87 69 001–128
XP-A *1 *2 *1
:: : :
XP-D *1 *2 *1
*1 Depends on the Wave Expansion Board installed.
*2 Fixed Bank Select numbers are assigned to the Wave
Expansion Board itself.
SR-JV80 Number Bank Select Program Change
Series MSB LSB Number
SR-JV80-01 001–128 89 00 001–128
SR-JV80-01 129–256 89 01 001–128
SR-JV80-02 001–128 89 02 001–128
SR-JV80-02 129–256 89 03 001–128
:: :: :
SR-JV80-65 001–128 91 00 001–128
SR-JV80-65 129–256 91 01 001–128
:: :: :
SR-JV80-99 001–128 91 68 001–128
SR-JV80-99 129–256 91 69 001–128
For details on the SRX Series, refer to the owner’s
manual for the SRX Series Wave Expansion Board.
<Example>
Selecting PR-B Patch number 10 from an external MIDI
device
Transmit data to the XV-88 in the following order.
(Numbers are given in decimal.)
Controller number 0 (Bank Select MSB) value: 87
Controller number 32 (Bank Select LSB) value: 65
Program Change number: 10
Selecting Rhythm Sets
The MIDI messages transmitted by the external MIDI device
will be received by the XV-88 to select Rhythm Sets as shown
in the following table.
Group Number Bank Select Program Change
MSB LSB Number
USER 001–004 86 00 001–004
CD-A 001–004 86 32 001–004
:::::
CD-H 001–004 86 39 001–004
PR-A 001, 002 86 64 001, 002
PR-B 001, 002 86 65 001, 002
PR-C 001, 002 86 66 001, 002
PR-D 001, 002 86 67 001, 002
PR-E 001, 002 86 68 001, 002
PR-F 001, 002 86 69 001, 002
XP-A *1 *2 *1
:: : :
XP-D *1 *2 *1
*1 Depends on the Wave Expansion Board installed.
*2 Fixed Bank Select numbers are assigned to the Wave
Expansion Board itself.
SR-JV80 Number Bank Select Program Change
Series MSB LSB Number
SR-JV80-01 001–128 88 00 001–128
SR-JV80-01 129–256 88 01 001–128
SR-JV80-02 001–128 88 02 001–128
SR-JV80-02 129–256 88 03 001–128
:: :: :
SR-JV80-65 001–128 90 00 001–128
SR-JV80-65 129–256 90 01 001–128
:: :: :
SR-JV80-99 001–128 90 68 001–128
SR-JV80-99 129–256 90 69 001–128
For details on the SRX Series, refer to the owner’s
manual for the SRX Series Wave Expansion Board.
