MIDI Implementation
Appendices
❍ Volume (Controller number 7)
Status 2nd byte 3rd byte
BnH 07H vvH
n = MIDI channel number:0H - FH (ch.1 - 16)
vv = Volume: 00H - 7FH (0 - 127)
* Not received in Performance mode when the Vol parameter (PERFORM/MIDI/
RxSWITCH) is OFF.
* In Performance mode the Level parameter (PERFORM/PART/SETTING) will change.
❍ Balance (Controller number 8)
Status 2nd byte 3rd byte
BnH 08H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Balance: 00H - 7FH (0 - 127)
❍ Panpot (Controller number 10)
Status 2nd byte 3rd byte
BnH 0AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Panpot: 00H - 40H - 7FH (Left - Center - Right),
* Not received in Performance mode when the Pan parameter (PERFORM/MIDI/
RxSWITCH) is OFF.
* In Performance mode the pan parameter (PERFORM/PART/SETTING) will change.
❍ Expression (Controller number 11)
Status 2nd byte 3rd byte
BnH 0BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Expression: 00H - 7FH (0 - 127)
* Not received when Expression parameter (PATCH/CONTROL/CTRL Rx MIDI or
RHYTHM/CONTROL/Rx MIDI) is OFF.
* Not received in Performance mode when Exp parameter (PERFORM/MIDI/
RxSWITCH) is OFF.
❍ Hold 1 (Controller number 64)
Status 2nd byte 3rd byte
BnH 40H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON
* Not received when Hold-1 parameter (PATCH/CONTROL/CTRL Rx MIDI or
RHYTHM/CONTROL/Rx MIDI) is OFF.
* Not received in Performance mode when Hld parameter (PERFORM/MIDI/
RxSWITCH) is OFF.
❍ Portamento (Controller number 65)
Status 2nd byte 3rd byte
BnH 41H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* In Performance mode the Portamento Sw parameter (PERFORM/PART/MONO/POL)
will change.
❍ Sostenuto (Controller number 66)
Status 2nd byte 3rd byte
BnH 42H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍ Soft (Controller number 67)
Status 2nd byte 3rd byte
BnH 43H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
❍ Legato Foot Switch (Controller number 68)
Status 2nd byte 3rd byte
BnH 44H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON
* In Performance mode the Legato parameter (PERFORM/PART/MONO/POL) will
change.
❍ Hold-2 (Controller number 69)
Status 2nd byte 3rd byte
BnH 45H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Control value: 00H - 7FH (0 - 127)
* A hold movement isn't done.
❍ Resonance (Controller number 71)
Status 2nd byte 3rd byte
BnH 47H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv= Resonance value (relative change): 00H - 7FH (-64 - 0 - +63),
* In Performance mode the Res parameter (PERFORM/PART/MODIFY) will change.
❍ Release Time (Controller number 72)
Status 2nd byte 3rd byte
BnH 48H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Release Time value (relative change): 00H - 7FH (-64 - 0 - +63),
* In Performance mode the Rel parameter (PERFORM/PART/MODIFY) will change.
❍ Attack time (Controller number 73)
Status 2nd byte 3rd byte
BnH 49H vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Attack time value (relative change): 00H - 7FH (-64 - 0 - +63),
* In Performance mode the Atk parameter (PERFORM/PART/MODIFY) will change.
❍ Cutoff (Controller number 74)
Status 2nd byte 3rd byte
BnH 4AH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Cutoff value (relative change): 00H - 7FH (-64 - 0 - +63)
* In Performance mode the Cut parameter (PERFORM/PART/MODIFY) will change.
❍ Decay Time (Controller number 75)
Status 2nd byte 3rd byte
BnH 4BH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Decay Time value (relative change): 00H - 7FH (-64 - 0 - +63)
* The decay time will change in GM mode.
❍ Vibrato Rate (Controller number 76)
Status 2nd byte 3rd byte
BnH 4CH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Rate value (relative change): 00H - 7FH (-64 - 0 - +63)
* The vibrato rate will change in GM mode.
❍ Vibrato Depth (Controller number 77)
Status 2nd byte 3rd byte
BnH 4DH vvH
n = MIDI channel number: 0H - FH (ch.1 - 16)
vv = Vibrato Depth Value (relative change): 00H - 7FH (-64 - 0 - +63)
* The vibrato depth will change in GM mode.
